Install the cooling system
•
Air Cooler
•
AIO Cooler
NOTE: Please refer to these manual(s) for more information:
Install the motherboard into the chassis
For non pre-mounted I/O
shield models only
NOTE: Please refer to the manual(s) for more information:
4
Q25669_PRIME_H610M-F_WIFI_D4_QSG.indd 4
Q25669_PRIME_H610M-F_WIFI_D4_QSG.indd 4
CPU_FAN / CPU_OPT
OR
AIO_PUMP / W_PUMP
(connect to pump)
Cooler
Chassis
Motherboard
Chassis
CPU_FAN / CPU_OPT
(connect to radiator)
