Install the M.2 SSD
M.2 slot
OPTIONAL
Install the bundled
M.2 rubber when
installing a single
sided M.2 module
Make sure of the following:
• M.2 Q-Latch
• Secure the
clicks and locks
screw properly
the M.2 SSD
Additional Information (on selected models)
M.2 Q-Release
Type-A
Type-B
NOTE: Please refer to the manual(s) for more information:
Q25669_PRIME_H610M-F_WIFI_D4_QSG.indd 3
Q25669_PRIME_H610M-F_WIFI_D4_QSG.indd 3
Remove
• Insert the pin
of the M.2 Anchor
into the hole
M.2 slot
OR
OPTIONAL
Install the bundled
M.2 rubber when
installing a single
sided M.2 module
Make sure the M.2 Q-Slide clicks and
locks the M.2 SSD
M.2 Q-Slide
Install
M.2 slot
Remove
M.2 slot
Motherboard
Remove
Optional
3
