1. Please ensure that the screws and nuts are tightened during installation.
For your safety, the product must be used in the specified size and weight
limits.
2. Ensure that the wall's quality and load-bearing capacity are sufficient for
installation. The manufacturer is not responsible for any consequences
arising from improper installation.
3. If installing in glass or glass curtain wall, foam brick, marble, fiberboard
board, please consult a professional installer before installation. Otherwise,
the manufacturer is not responsible for any consequences caused by
improper installation!
A B
Fixed Iron
M6*12mm
2PCS
F G
M8*16mm Φ8*Φ17*1.7mm
4PCS
ATTENTION
PARTS LIST
C
M8
4PCS
H
Φ7*Φ10*60mm
4PCS
3
D
M8*12mm
4PCS 4PCS
I
M7*70mm
4PCS 6PCS
E
M6*16mm
4PCS
