Connection to the indoor unit
This terminal allows the Aidoo Pro device to communicate with the indoor AC unit or the
thermostat via the connection cable.
Note: both the shape of the terminal on the Aidoo Pro device and the shape of the cable may
vary depending on the compatible manufacturer.
Diagnostic LEDs
Transmission of data to the indoor unit
Reception of data from the indoor unit
Digital input
Configurable voltage free input to switch the unit on/off or activate the refrigerant leakage
operation logic of the Aidoo Pro device.
Note: it is recommended that the wiring of the digital inputs be routed through a separate
conduit.
Relay output (12 V) - Auxiliary heat
12 Vdc relay output for the control of the Auxiliary Heat function.
Note: for further information see "Settings from Airtools on Airzone Cloud" in the "Advanced
Settings" section.
Power supply input
12 Vdc input that enables providing power to the Aidoo Pro device.
The 230 Vac - 12 Vdc power supply is supplied with the device.
Meaning
Connecting to a Wi-Fi network
Connected to a Wi-Fi network
Connected to the server
Not configured
Cloud Communications
Microprocessor activity
Power supply
Blinking
Green
Steady
Steady Blue
Off -
Blinking Red
Blinking Green
Steady Red
Blinking Red
Blinking Green
