Technical Data
Electrical data
Battery
lead-fleece battery, maintenance-free, 6 V, 4.5 Ah
Service life
Battery
> 0.5 years at 50 °C
> 4 years at 25 °C
LED
> 50,000 h at 50 °C
Luminous
characteristics
Lamps
main light, LED: 3 W
secondary light, LED: 0.5 W
Light intensity
24,000 cd
CCT
6500 K
Light distribution
acc. to DIN 14642
Functions
continuous light or flashing light of the main light, continuous light of the
secondary light, function of the main light continuously dimmable
Emergency light
main light:
duration
secondary light:
Deep discharge
At a residual capacity of the battery of < 10 %, the main light is automatically
protection
switched to the secondary light.
Test function
Lamp control
When the main light is defective, the light is switched automatically to the
secondary light
Battery capacity
Determination of the current battery capacity
Mechanical data
Degree of protection
IP66 (IEC/EN 60529)
Enclosure material
Polyamide, impact-strength
Head tilting
toward the front: 100°, toward the back: 90°
Pushbutton
main light ON - secondary light ON - main light FLASHING OFF
Charge state display
The LEDs indicate the available capacity for approx. 5 seconds
Ambient conditions
Ambient temperature -20 ... +50 °C
Storage temperature -20 ... +50 °C
Charging unit
Version
charging unit LG 200 (for explosion-protected portable lamps)
supply voltage: 110 ... 240 V AC, 50 / 60 Hz and 12 ... 30 V DC
with emergency lighting function and automatic break device for motor vehicle
operation
with power supply cable for 110 ... 240 V AC, 50 / 60 Hz
Optionally, a charging cable for motor vehicle operation for 12 ... 30 V DC
is available.
continuous duty:
continuously on, typical 7 h
flashing mode:
flashing up to 18 h
continuous duty: continuously on, typical 32 h
Portable Lamp
SHL 200-Ex
Technical data
