STABILUS 011052 Einbauanleitung Seite 3

English
Part Number: 011052
VW Arteon
Generation: 2017
OE Numbers:
3G8 827 851 A
3G8 827 851 B
3G8 827 851 C
3G8 827 851 E
Stabilus GmbH
Wallersheimer Weg 100
56070 Koblenz
Germany
T +49 261 - 8900-0
info@stabilus.com
www.stabilus.com
Installation Instructions
Only authorized personnel should perform the installation. Always refer to the manufacturer's
guidelines for specific instructions and safety precautions.
Step 5:Insert the grommet
• Ensure proper insertion of the grommet into the vehicle.
• Use a drop of dish soap to ease installation.
• Confirm that the grommet length is correct.
• Prevent the grommet from coming into contact with the
bodywork (except for cable routing), and avoid placing
the grommet under tension during this process.
18
• If necessary, readjust.
Step 6:Set up the control unit
After reassembling the panel:
• Close the tailgate manually until the lock is engaged.
• Open and close the hatch automatically (learning run).
Caution: Be mindful of the Push-To-Run function in some electric tailgate systems; moving
the tailgate too quickly during setup can cause complications.
Step 7:Set the desired hatch position
• Manually open the hatch to the desired position.
• Program the drive accordingly by pressing and holding
the closing button on the hatch until a signal is received.
• Make sure that the tailgate only opens to the
programmed position now by closing and opening the
tailgate automatically again.
Page 3
