8.4
Battery capacity indicator (Fig. A)
There are battery capacity indicators (22) on the battery pack, you can check the capacity
status of the battery if you squeeze the button (23). Before using the machine, please press
switch trigger to check if the battery is full enough for properly working.
Those 3 LED might show the status of the capacity level of the battery:
▪
3 LED's are lit: Battery fully charged.
▪
2 LED's are lit: Battery 60% charged.
▪
1 LED is lit: Battery almost discharged.
9 ASSEMBLY
9.1
Lower handle assembly
Insert pin into the round hole (25) of the lower handle on both left and right side. (Fig. 2)
Insert the square neck bolt (24) into the bracket (5) and lower handle (4), then tighten with the
fixing knob (9)
NOTE: The handle level (high, medium and low) (Fig. 3) can be adjusted by
setting the square neck bolt (24) in one of the three holes on the bracket (5).
9.2
Upper handle assembly
▪
Insert the square neck bolt (24) into the lower handle (4) and the upper handle (3) in turn,
then tighten with the fixing knob (9). (Fig. 4)
▪
Fasten the cables with the clips (Fig. 5) on the lower handle (4) making sure the cables
pass on top of the handle support (5). Fastening the cable on the underside of the handle
(4) may cause the cables to break when folding down the upper handle assembly (3).
9.3
Collection box-bag assembly
Hold up the rear cover (26) and slide the clamps of the collection box-bag (10) on the
machine. (Fig. 6)
9.4
Grass collection settings
1
Rear discharging
a.
b.
2
Side discharging
a.
b.
c.
3
Mulching
a.
b.
9.5
Working depth setting (Fig. 10)
▪
Remove key (7) and battery pack (19).
▪
To raise the blade height, grasp the height adjustment lever (11) and move it toward the
front of the mower.
▪
To lower the blade height, grasp the height adjustment lever (11) and move it toward the
back of the mower.
Copyright © 2025 VARO
Install the collection box-bag (10).
Close the rear cover (26).
Close the rear cover (26).
Unlock the handle by pushing on the release mechanism. (Fig. 7)
Afterwards you can open the side cover (27) and install the discharge
guard. (Fig. 8).
Lift and hold up the rear cover (26), afterwards insert the mulching plug
(28). (Fig. 9)
Close the rear cover.
POWDPGLMS5
P a g e
| 10
EN
www.varo.com
