Mosaic
TM
Surge arrester
7. TECHNICAL CHARACTERISTICS
7.4 Climatic characteristics
Storage temperatures : - 20°C to + 60°C
Operating temperatures : - 5°C to + 40°C
8. CLEANING
8.1 Cleaning
Clean the surface with a slightly damp cloth.
Do not use : tar remover, acetone, trichloroethylene.
8.2 Replacing the fuse (Cat. No. 775 42 only)
9. SPECIAL USES
• Regularly check that the indicator light is on.
• Favour the use of an S-type circuit breaker for modular equipment
only.
• If the circuit-breaker cannot be reset, remove the plug-in module.
• Do not exceed 6 A for Cat. No. 775 42.
10. ACCESSORIES
Supplied with :
• 1 instruction leaflet
• 1 hole base label to be fixed in the socket outlets, indicating the cur-
rent limit at 6 A (Cat. No. 775 42 only).
11. CONFORMITY - APPROVALS
Approvals in process Cat. No. 775 40/41 : NF
Technical sheet : F00426EN/01
(cont'd)
Fuse
to be replaced
Spare
fuse 6.3 A
Updated : 11/01/2008
Cat. No(s) : 775 40/41/42
Created : 24/10/2007
3/3
