Surge arrester
775 40/42
1. USE
Protection between phase and neutral of socket outlets connected
downstream against overvoltages generated by the electrical network
upstream of the voltage surge protector, by creating a discharge cur-
rent on the network and/or ground connection.
To be used in addition to panel-connected voltage surge protectors.
2. RANGE
Designation
Surge arrester
Surge arrester
cartridge
Filter
3. PREPARATION
Surge arrester + cartridge (Cat. No. 775 40/41) :
Filter (Cat. No. 775 42) :
Technical sheet : F00426EN/01
Cat. No.
No. of modules
Weight (g)
775 40
2
775 41
775 42
2
Updated : 11/01/2008
87045 LIMOGES Cedex
Telephone : 33 0 5 55 06 87 87 - Fax : 33 0 5 55 06 88 88
Cat. No(s) : 775 40/41/42
775 41
4. OVERALL DIMENSIONS
104
65
55
5. CONNECTION
Installation method Cat. No. 775 40/41
SPD
Surge
Modular
Protective
surge
Device
protector
PE
CONTENTS
1. Use . . . . . . . . . . . . . . . . . . . . . . . . . .1
2. Range . . . . . . . . . . . . . . . . . . . . . . . .1
3. Preparation . . . . . . . . . . . . . . . . . . . .1
4. Overall dimensions . . . . . . . . . . . . . .1
5. Connection . . . . . . . . . . . . . . . . . . . .1
6. Operation . . . . . . . . . . . . . . . . . . . . . .2
7. Technical characteristics . . . . . . . . . .2
8. Cleaning . . . . . . . . . . . . . . . . . . . . . .3
9. Special uses . . . . . . . . . . . . . . . . . . .3
10. Accessories . . . . . . . . . . . . . . . . . . . .3
11. Conformity - Approvals . . . . . . . . . . .3
14.4
32.5
45
30 mA
N
L
Created : 24/10/2007
Page
L
N
1/3
