Natec EUPHONIE PRO Benutzerhandbuch Seite 3

EN
INSTALATION
Pairing a new device with mouse in Bluetooth mode
• Turn ON Bluetooth on device you want to pair with the mouse.
• Move the switch located at the bottom of the mouse to position indicated by the symbol BT and hold the
blue button "CONNECT" for about 5 seconds to enter into pairing mode. The OLED display should appear
information "Pairing".
• Then go to the Bluetooth settings on your device and select from the list of mouse Natec Euphonie Pro
• After successful pairing the OLED display should appear information "Connected"
• The mouse is ready for use
Connecting the mouse with the previously paired device
• Turn ON Bluetooth on your device that you have previously paired with the mouse
• Turn ON or wake up the from hibernation
• The mouse will automatically connect with the device
Connecting the mouse via USB receiver
• Turn ON your computer or other compatible device
• Move the switch located at the bottom of the mouse to the position indicated by the symbol 2.4G
• Connect the receiver to a free USB port on your computer
• The operating system will automatically install the required drivers
• The mouse is ready for use when the OLED display appear information "Connected"
Note:
• The device is equipped with intelligent technology for energy management. When the mouse enter into
hibernation (sleep) mode, press any button of the mouse for its revival.
• The mouse is equipped with an ON/OFF switch to save the battery power when not in use for longer
period.
BUTTONS DESCRIPTION
1. Left button
2. Right button
3. Scroll click
4. Backward
5. Forward
6. DPI / Programming mode
7. Left button
8. Right button
9. Double click
PROGRAMMING MOUSE BUTTONS
Mouse allows programing only those five buttons: 4, 5, 7, 8, 9
1. Hold the DPI button for about 3 seconds to enter into programing mode. On the OLED display will
appear programming interface "setting interface".
2. Press the button you want to program. On the OLED display will appear selection of available functions.
3. Select required function by moving the scroll wheel and press again previously selected button.
4. If you want to program another button repeat steps 2 and 3.
5. Hold DPI button for about 3 seconds to save selected functions and exit from programming mode.
Restore factory settings: If you want to restore factory settings and reset programmed functions,
simultaneously hold down buttons 1 + 2 + 3 about 5 seconds.
CHARGING THE BATTERY
• Connect the included USB-C cable to the mouse
• Connect USB plug to a suitable power source (max. output DC 5V 1A)
Note: Mouse can be used during charging.
Caution: Please charge the battery every 3 months, if you do not use the mouse for a long time. Long-term
storage of the mouse with low battery level, or using the chargers with power over 5V 1A may damage the
battery.
USER MANUAL
7
6
8
3
2
1
1
OLED
4
5
9
