MANUAL
IGNITE
Art. no
38469
PRODUCT OVERVIEW
The Ignite packaging contains the following parts:
• Lamp unit
• Rechargeable battery (96 Wh)
• Head mount
• Extension cable
• Charger + EU/US/UK plugs
• Quick Guide
PERFECT LIGHT
To create the perfect, and the strongest light, Ignite is built with world class Cree® XLamp®
XHP50.2 LEDs and Ledil TINA2-RS lenses. The Cree LEDs are the next generation of extreme
high power LEDs that deliver the best lumen density, reliability and colour consistency. The
Ledil lenses offer the perfect beam angles and high UV and temperature resistance.
SILVA INTELLIGENT LIGHT
Silva Intelligent Light optimizes the light pattern by the unique combination of a long reach
spot light and a close flood light. With less head movements and a clear view of near as well as
far obstacles, you gain the balance and confidence it takes to move fast and perform better.
BEFORE USE
BATTERY CHARGING (96 Wh battery)
The battery needs to be charged before first use.
1. The charger comes with 3 interchangeable plugs for EU, UK and US. Choose the plug that
fits your wall outlet, slide the plug onto the charger until you here a click.
2. Connect the battery cable to the charger cable.
3. Connect the charger to a wall outlet.
4. On the battery, there are 5 LEDs showing battery status during charging:
• Green light (all 5 LEDs) = battery is fully charged
• Red light blinking = battery is charging
Charge time is approximately 4 hours.
Note! When the battery is fully charged the charger automatically switches to maintenance mode.
Note! Never leave a battery unattended during charging.
Note! The battery can not be charged while connected to the accessories (extension cable /
double battery connector).
ACCESSORIES AND MOUNT OPTIONS
Ignite is designed for multiple activities and can easily be switched between the different
mount accessories. The battery can also be carried in multiple ways by using the different
battery accessories and cords. All accessories can be bought separately.
HEAD MOUNT
Ignite Head Mount is ergonomically shaped to give you a comfortable fit and optimal weight
distribution. Adjust the head mount with the 5 different Velcro adjustments.
Attach the lamp by sliding the lamp foot down into the snap bracket. To remove, slide the
headlamp up and out of the bracket. Use the two loops on the top of the head mount to guide
the cable to the battery.
EXTENSION CABLE
The extension cable gives you 90 cm extra cable length between the lamp unit and the bat-
tery, allowing you to place the battery further from the battery than what is possible with the
integrated cables, e.g. a backpack, pocket or similar. The battery can not be charged while
connected to the extension cable.
REMOTE CONTROL (SOLD SEPARATELY)
The Ignite Remote Control is connected to your Ignite Headlamp via Bluetooth* and will help
you to easily switch between the five light modes. Boost the light when in technical terrain,
or dim down when meeting other people. The remote will also inform you about which bright-
ness level you are currently running on, and the battery level of both the headlamp and the
remote control itself.
*Read more about Bluetooth synchronization under "Controlling the lamps light modes with
the remote control"
BATTERY CHARGING (Remote control)
The remote control has an integrated, rechargeable battery with USB-C connection.
1. To access the charge port - carefully lift the rubber lid on the side of the remote.
2. Connect the USB-C plug of the charge cable to the charge port on the remote.
3. Connect the other end (USB-A) of the charge cable to a wall charger or directly to a
computer.
4. On the remote, there are 5 LEDs showing battery status during charging:
• Green light (all 5 LEDs) = battery is fully charged
• Red light blinking = battery is charging
Charge time is approximately 5 hours.
REMOTE CONTROL - WRIST BAND (SOLD SEPARATELY)
The wrist band is attached and adjusted with Velcro and can be hand washed. Attach the
remote to the wrist band by sliding it (in direction towards the plus button) into the snap
socket until you hear a click. To detach, slide it out of the socket in direction towards the
minus button.
REMOTE CONTROL - BAR MOUNT (SOLD SEPARATELY)
The bar mount for the remote control is attached to the bar with the integrated rubber strap.
Pull the rubber strap around the bar and fasten it on the plastic hook. The mount fits poles or
bars with a diameter of 22-35 mm.
Attach the remote control to the bar mount by sliding it (in direction towards the plus button)
into the snap socket until you hear a click. To detach, slide it out of the socket in direction
towards the minus button.
HELMET MOUNT (SOLD SEPARATELY)
The helmet mount comes with:
• 1 double adhesive pad.
• 1 friction pad with one adhesive side and one rubber side.
• 2 attachment straps.
The Ignite Helmet Mount is designed to fit most helmet types and can be mounted in two
different ways by using the different pads/straps.
• You can use the double adhesive pad to attach the helmet mount to your
favourite helmet. First, remove the protective film that covers one side of
the pad and attach the pad to the back side of the helmet mount. Then
remove the protective film from the other side of the pad and firmly press
the helmet mount in correct position onto the helmet. Make sure that the
surface of the helmet is clean and dry. For optimal effect - you should leave
the attachment in this state for at least 24 hours before using it with the lamp.
• If you do not want to use the double adhesive pad on your helmet - you can use the
friction pad instead. The pad creates friction and prevents the helmet mount from sliding.
With this method, the helmet mount can be switched between different
helmets. First, remove the protective film that covers the adhesive side of
the pad and attach the pad to the back side of the helmet mount. Then
remove the protective film from the rubber side of the pad. Place the
helmet mount in correct position on the helmet and use the attachment
straps with the ventilation holes (or other attachment points) on the helmet.
Once the helmet mount is attached to the helmet, you can easily slide the lamp in and out of
the bracket. Attach the lamp by sliding the lamp foot down into the bracket. To remove, slide
the headlamp up and out of the bracket.
BAR MOUNT (SOLD SEPARATELY)
The bar mount is designed to fit bars with a diameter of 31.8-35 mm. Attach the bar mount by
placing it around the bar and lock it into position by tightening the screw (no tools needed).
The bar mount can be used either with or without the rubber inserts to better adapt to
the specific bar diameter. Once the bar mount is attached to the bar, you can easily slide
the lamp in and out of the bracket. Attach the lamp by sliding the lamp foot down into the
bracket. To remove, slide the headlamp up and out of the bracket.
BATTERY SLEEVE (SOLD SEPARATELY)
Ignite Battery Sleeve is for mounting the Ignite Battery 96 Wh to your bike
frame or wherever you find suitable. The sleeve is made of neoprene and it
has silicone friction prints on the inside to hold the battery in place, and Velcro
straps for easy mounting on most frames and configurations. Pull the sleeve
over the battery, then attach the straps to the Velcro surface of the sleeve. Pull
the straps tightly around the battery and the frame and attach the Velcro.
DOUBLE BATTERY CONNECTOR (SOLD SEPARATELY)
The Ignite Battery 96 Wh can be bought separately as an extra accessory if you need a
backup battery or an additional battery to extend the burn time. To enable longer burn time
without having to stop and switch batteries - two batteries can be connected at the same
time by using the Double battery connector. The adaptor connects the batteries in parallel
and doubles the battery time - everything else on the lamp works as usual. The connected
batteries can have different charge levels without it affecting the function. The batteries can
not be charged while connected to the adaptor.
BATTERY HARNESS (SOLD SEPARATELY)
Ignite Battery Harness is a lightweight and ergonomic carrier, shaped like a running vest to
carry your Ignite 96 Wh battery during fast paced activities. It has a large pocket in the back
that holds 1-2 batteries, 2 mesh pockets in the front for gels or bars, and a compression strap
to hold the battery firmly in place or to carry a wind jacket etc. The harness has a total of 7
different adjustment points. Optimize the fit and weight distribution by adjusting the length
of the shoulder straps, the attachment points in the back and the length and vertical position
of the chest strap. The harness can be hand washed and weighs 170 grams.
G P MOUNT (SOLD SEPARATELY)
o ro
Ignite GoPro Mount makes your Ignite headlamp compatible with GoPro camera mounts.
Attach the bracket to the GoPro camera mount with a GoPro thumb screw. Once the bracket
is in place, you can easily slide the Ignite headlamp in and out of the bracket. Attach the lamp
by sliding the lamp foot down into the bracket. To remove, slide the headlamp up and out of
the bracket.
