1. LEGEND OF FUNCTIONS
1.1 Parent Unit
4 5
3
2 6
Link Power
7
1
FRONT
Link Power
(1) Mute button
(2) Link / Unlinkindicator
LED
(3) Talk back button
(4) Sound level light
(5) Volume / VOX
sensitivity +- control
8
(6) Power / charging
indicator LED
(7) ON/OFF button
(8) Belt clip
9
(9) Battery
compartment
(10) Power adapter jack
for the charger
BACK
10
(11) Parent unit charger
11
(12) Charger light
12
2
1.2 Baby Unit
3
2
1
FRONT
BACK
4
(1) Link / Unlink
indicator LED
6
(2) Night light
(3) Night light ON/OFF
5
button
(4) Volume +- control
(5) Power / Battery low
indicator LED
(6) ON/OFF button
(7) Power adapter jack
(8) Battery compartment
cover lock
(9) Battery compartment
7
8
9
