Plunge routers
Part number
Rated power
Output power
No-load speed
Dust Extraction
Tool holder
- with special accessory
Stroke of the router base
Weight (without optional
extras) app.
Safety class
1 On/Off switch
2 Scale
3 Depth stop
4 Wing bolt for depth stop adjustment
5 Ground plate/Base plate
6 Collet chuck
7 Tightening nut with collet
8 Hand grip (turn to lock)
9 Spindle locking pin
10 Open-ended spanner
11 Screws (2 x)
12 Suction adapter
13 Guide bushing
14 Winged screw for parallel guide
15 Guide rail
16 Parallel guide
17 Centering pin
18 Winged screw
Not all of the accessories illustrated or described are
included as standard delivery.
The machine is intended for routing in wood, plas-
tic and light building materials of grooves, edges,
profiles and elongated holes as well as copy rout-
ing while resting firmly on the workpiece.
Measured values determined according to
EN 50 144.
Typically the A-weighted sound pressure level of
the tool is 75 dB (A). The noise level when work-
ing can exceed 85 dB (A). Wear ear protection!
The weighted acceleration is typically 4,0 m/s
2 609 929 749 • TMS • 11.10.00
POF 400 A
0 603 261 1..
400 W
230 W
-1
27 000 min
•
In addition, the general safety instructions in
6 mm
the enclosed booklet must be followed. Be-
1/4 " / 8 mm
fore using for the first time, ask for a practical
48 mm
demonstration.
1.8 kg
/ II
Never allow children to use the machine.
Connect machines that are used in the open
via a residual current device (RCD) with an ac-
tuating current of 30 mA maximum. Use only
extension cables that are approved for outdoor
use.
Insert the mains plug only when the machine is
switched off.
Before putting into operation, check the routing
tool for firm seating.
Use only routing tools whose allowable speed
is at least as high as the highest no-load speed
of the machine.
The shaft diameter of the routing tool must cor-
respond with the stated diameter of the tool
holder (collet chuck).
Always direct the cable to the rear away from
the machine.
Apply the machine to the workpiece only when
switched on.
When working with the machine, always hold it
firmly with both hands and provide for a secure
stance.
Never route over metal objects such as nails or
screws.
Keep hands away from rotating router bits.
After finishing the job, return the machine to the
initial position by loosening the hand grip 8.
Protect tools from impact and shock.
Bosch is only able to ensure perfect functioning
of the machine if the original accessories in-
2
.
tended for it are used.
English - 1
Working safely with this machine
is possible only when the operat-
ing and safety information are
read completely and the instruc-
tions contained therein
strictly followed.
If the mains cable is damaged or cut
through while working, do not touch
the cable but immediately pull the
mains plug. Never use the machine
with a damaged cable.
Wear safety glasses and sturdy
shoes.Wear ear protection.
For long hair, wear hair protection.
Work only with closely
clothes.
are
fitting
