CONTENT OF DELIVERY
➢ Main unit
➢ Instruction manual
POWER SUPPLY
➢ Ensure that the voltage is the same as that indicated on the model identification plate.
➢ Connect the supplied power cable to a properly installed safety power socket and at the
mains connector AC on the right side of the unit.
BATTERY OPERATION
1. Open the lid of the battery compartment at the back side of the unit.
2. Insert 4 batteries of type UM-1 ("D" size) 1.5 V. Please ensure that the polarity is correct (see
indicated in the battery compartment).
3. Then close the battery lid.
VERY IMPORTANT
If nobody turns the unit OFF after stopping playing or no audio signal, the unit will power
off automatically after around 20 minutes.
Turn the unit OFF and ON again to resume playing. This is no technical error!
POWER ON / OFF
Set the "FUNCTION" switch to "RADIO", "MP3/BT" or press a cassette function button to turn on
the unit.
Set the "FUNCTION" switch to "OFF/TAPE" or take care that no cassette function button is
pressed.
ADJUSTING VOLUME
Rotate the "VOLUME" knob to adjust the desired volume.
SOUND ADJUSTMENT
Rotate the "TREBLE" or "BASS" knob to adjust the sound.
Set the "FUNCTION" switch to the "RADIO" position
1.
Set the "BAND" switch to "FM", "AM" or "SW" position.
2.
Rotate the "TUNING" knob to search the desired radio station.
3.
Note:
➢ When operating in "FM" and "SW" band radio, pull out the TELESCOPIC ANTENNA
completely and adjust the position to get a better reception.
INSTALLATION
➢
Power cable

BASIC OPERATION

RADIO
2
RR20 / English Instruction Manual
