General technical approval/
General design certification
No. Z-40.21-432 of 08 September 2020
Blow-moulded containers made of polyethylene (PE-HD)
with integrated collection container made of galvanised
sheet steel Type UNI-Tank 1500 l
Container system
Packaging, transportation and storage
1
Moulding compound for inner containers
(1) Only the moulding compound detailed in Table 1 below with the material properties described
there may be used to manufacture the inner containers.
Table 1: Moulding compounds, material properties
Type designation
Manufacturer
Designation according to DIN EN ISO 17855-1
Alcudia 49070 UV
Repsol Quimica
ISO 17855-PE-HD, BAHN, 50-G090
(2) The moulding compound must be processed with at least 70% virgin material and a maximum
of 30% single-origin return compound. The use of regranulates is not permitted.
2
Collection container (outer container)
Material: galvanised sheet steel according to DIN EN 10346
Casing:
DX 51 D+ Z 275 or ZA 255
End parts:
DX 52 D+ Z 275 or ZA 255
Cover:
DX 53 D+ Z 275 or ZA 255
Sealing material for flanged seam (see stored documents):
-
oil-resistant sealant "Duraflex KN 9 PU" from Arawerke,
-
alternatively: NBR seal 6 x 1 one-sided self-adhesive
3
Base frame
Material:
S 235 JR, hot-dip galvanised or
Material:
DX 51 D Z275 or DX 51 D ZA 255
Sheet thickness/dimensioning for the respective base frame are listed in Annexes 1.2 to 1.4.
4
Container accessories, spacers
The materials and details are listed in the drawings in the annexes and the stored documents.
1
DIN EN ISO 17855-1:2015-02 Plastics - Polyethylene (PE) moulding and extrusion materials - Part 1: Designation
system and basis for specifications
2
DIN EN 10346:2009-07
Continuously hot-dip coated steel flat products; Technical delivery conditions; English
version EN 10346:2009
Z72345.20
1.40.21-55/20
General technical approval/
General design certification
No. Z-40.21-432 of 08 September 2020
Blow-moulded containers made of polyethylene (PE-HD)
with integrated collection container made of galvanised
sheet steel Type UNI-Tank 1500 l
Container system
Packaging, transportation and storage
1
Packaging
It is not necessary to package the containers for transportation or for (temporary) storage, provided
the requirements set out in Section 2 are met. It must be possible to close all nozzle openings
using the screw caps.
2
Transportation and storage
2.1
General provisions
The containers may only be transported by companies possessing professional experience,
appropriate equipment, facilities and means of transportation, and adequately trained personnel.
The relevant accident prevention regulations are to be observed with a view to avoiding risk for
employees and third parties.
2.2
Transportation preparation
(1) The containers are to be prepared for transportation in such a way that they cannot be
damaged during loading, transportation and unloading.
(2) The loading area of the vehicle used for transportation must be designed in such a way that
the containers cannot be damaged by point impacts or loads.
2.3
Loading and unloading
(1) When hoisting, moving and lowering the containers, impact-type loads must be avoided.
(2) If a forklift truck is used, the container must be secured while it is being transported on the
forklift truck.
(3) Nozzles and other protruding parts of the container must not be used for the purposes of
securing or hoisting the container. It is not permitted to drag containers across the ground.
2.4
Transport
(1) The containers must be secured against movement during transportation.
(2) The method used to secure the container must not result in it becoming damaged.
2.5
Storage
(1) Where containers are being temporarily stored in outdoor areas, they must be protected
against damage and the effects of storms, and protected from direct exposure to UV rays (inner
containers). The containers must not be exposed to outdoor weathering for more than 6 months.
(2) It is essential to ensure that no rainwater is able to penetrate between the inner container and
the collection container.
2.6
Damage
Where damage has occurred during transportation or storage, the containers should be handled
in accordance with the findings of a competent expert according to water law, or the
certification body.
Z72345.20
1.40.21-55/20
Annex 2
MFR 190/21.6
Density at 23 °C
[g/10 min]
[g/cm³]
1
8.5 ± 1.5
0.949 ± 0.002
2
Sheet thickness: 1 mm
Sheet thickness: 1 mm
Sheet thickness: 0.75 mm
Annex 3
General technical approval/
General design certification
No. Z-40.21-432 of 08 September 2020
Blow-moulded containers made of polyethylene (PE-HD)
with integrated collection container made of galvanised
sheet steel Type UNI-Tank 1500 l
Container system
Certificate of conformity
1
Factory production control
1.1
Materials
(1) For the material listed in Annex 2, Table 1, the verifications specified in Table 1 must be
performed, whereby the monitoring characteristic values specified in Table 2 must be complied
with as minimum and maximum values.
(2) The average for each of at least three individual measurements must be calculated when
determining values.
Table 1: Material tests and documentation
Object
Property
Test
specification
Moulding
Trade name,
compound
designation of
moulding compound
type according to
DIN EN ISO 17855-1
Annex 2,
Section 1
MFR, density
Moulding
MFR, density
Annex 4,
material
Section 1.1,
Table 2
Table 2: Material characteristics (monitoring characteristics) for inner container
Object
Density [g/cm³]
according to DIN EN ISO 1183-1
Moulding
see Annex 2, Section 1
compound
Moulding
d
+ 0.004 ≥ d
R(e)
R(a)
material
Index a... before processing on the moulding compound
Index e... after processing on the moulding material
1
DIN EN 10204:2005-01
Metallic products – Types of test certificates
2
DIN EN ISO 1183-1:2004-05
Plastics – Methods for determining the density of non-cellular plastics – Part 1:
Immersion method, liquid pyknometer method and titration method
3
DIN EN ISO 1131-1:2012-03
Plastics – Determination of the melt mass-flow rate (MFR) and melt volume-flow rate
(MVR) of thermoplastics – Part 1: Standard method
Z72345.20
1.40.21-55/20
General technical approval/
General design certification
No. Z-40.21-432 of 08 September 2020
Blow-moulded containers made of polyethylene (PE-HD)
with integrated collection container made of galvanised
sheet steel Type UNI-Tank 1500 l
Container system
Certificate of conformity
1.2
Container (inner container)
(1) The tests described in Table 3 must be carried out on the inner containers, whereby the
measured values detailed in Table 4 must be complied with.
Table 3: Tests and test specification
Property
Test specification
Surfaces
based on DVS 2206-1
Wall thicknesses,
see Table 4 of this
container masses
Annex
see Section 1.2(2) of
Leakproofness
this annex
Overflow volume and
difference in overflow
see Section 1.2(3) of
volume for containers
this annex
in container systems
Table 4: Minimum wall thicknesses, container dimensions for inner tank
Property
Measuring point/stipulation
Wall thickness [mm]
at the corners and edges
in the bottom area
in the remaining areas (surfaces)
Mass [kg]
Container without fixtures
(2) The test pressure must be set at 1.3x the static pressure of the liquid to be stored, but at least
that of water, relative to the bottom of the container.
(3) The difference of the overflow volume ΔV for containers (inner containers) in container systems
(volume difference) must meet the requirement specified below:
ΔV = V
- V
≤ 1% V
max
min
min
V
: Overflow volume of the largest container of the container system
max
V
: Overflow volume of the smallest container of the container system
min
4
Data sheet DVS 2206-1:2011-09
Non-destructive tests on tanks, apparatus and piping made of thermoplastics –
Dimensional checking and visual inspection
Z72345.20
1.40.21-55/20
GB
Annex 4
Page 1 of 3
Documentation
Frequency
Acceptance test
certificate 3.1 in
accordance with
DIN EN 10204
1
every
consignment
Recording or
Acceptance test
certificate 3.1
according to
DIN EN 10204
1
Record
After
operational
start-up or
batch change
MFR [g/10 min]
2
in accordance with DIN ISO 1133 -1
3
max. MFR(e) ≤ 1.15 x MFR(a)
Annex 4
Page 2 of 3
Documentation
Frequency
4
every container
Record
in accordance with the
certification body
Value
above
4.1
below
5.5
5.6
3.7
48.0
