Nacon REVOLUTION X UNLIMITED Schnellstartanleitung Seite 4

EN /
I CONTROLLER ELEMENTS
2
1
9
13
12
20
1. Left joystick
2. View button
3. Screen
4. Menu button
5. Action button
6. Right joystick
7. Nexus button
8. Share button
3 4
8 6
7
19 18 17
16
9. D-pad
10. Mute button
11. 3.5mm jack socket
12. Right trigger (RT)
13. Right shoulder (RB)
14. Left shoulder (LB)
15. Left trigger (LT)
16. Shortcut 1 (S1)
5
23
14
15
22
21
17. Multi-function button
18. USB-C Socket
19. Lock button
20. Shortcut 2 (S2)
21. Shortcut 4 (S4)
22. Shortcut 6 (S6)
23. Right instant trigger blocker
24. Profile button
10
11
26
24 25 27
29
30
25. Mode button (wired, Bluetooth
wireless 2.4GHz)
26. Charging pin
27. Classic/Advanced mode button
28. Left instant trigger blocker
29. Shortcut 3 (S3)
30. Shortcut 5 (S5)
31. Reset hole
28
31
,
®
