Contents
Correct use
Unpacking
Commsioning
Systemconfiguration
Operating modes
Settingthe nominal t emperature
Settingthe HI-TEMP
Replacingextension cable and sensor
Errormessages
Analog output
Accesories
Technical data
e
Spar
partslist/ Spare partsdiagram
Correct
use
The IKATRON ETS-D4 fuzzyis an instrumentfor the
precisecontrol of temperatures.The sensorof the
instrument mustbeimmersed a tleast20mmdeepin
the mediumto be tempered.
TheInstrument canbe connected to anymagnetic
agitator with contact thermometer connection which
conforms with the requirements listed In the
TechnicalData (see section TechnicalData).
Unpacking
Please unpackthe machine carefully and inspect f or damage. I t is
importantthat any transit damage should be noted at the time of
unpacking
.
Incertain circumstances it maybenecessary t o investigate
immediately(post, railor freightforwarder).
As supplied, thepackage c ontains: oneIKATRON ETS-D4 f uzzy andone
setof operatinginstructions.
Page
8
Commissioning
8
8
Plug theinstrument intothecontact t hermometer jackonthemagnetic
8
agitator (e.g. IKA RCTbasic or IKA RET basic).The instrument is activa-
9
tedwhentheagitator i s switched on.If thereis novoltage supply bet-
9
ween 8V and 16VDCat the contactthermometerjack,the instrument
9
must berunoff the H52powersupplykit (H50twin-jack adapterandH51
10
plug powersupply).Theinstrumentwill then rece•ve the requiredvolta-
10
ge from the power supplyor twin-jackadapter.
10
An automaticself-testis performedwhen the Instrumentis activated.
10
Duringthe self-testall the segments of the LCDdisplayarevisible
10
(Fig.l).ThentheLCDdisplays i llustrated inFig.2to Fig.7appear ( stan-
14/15
dardfactorysetting).
System configuration
Before starting to workwiththeETS-D4 f uzzy thesystem configuration
must be set. Todo this, hold down the -
Setting the type of sensorused
TheLCDdisplayindicates the settypeof sensor,e.g.H62 (Fig.8).
Accessories seepage7.Usethe"+" and"-" keys tosetthetype
of sensorH 60
down oneof the two keysfor approx 2 seconds.Thedisplayed
sensor is set and stored if no key is pressed for approx. 5
seconds.
Setting the extension cable used
2.
TheLCDdisplay indicates t hesettypeofextension cable (Fig.9)
in smallletters.Thesettingis madeby pressingthe "+" and
keys.Possible settingsare:H70, H 71 or — if no extension cable
is used.Thedisplayed extensioncableis set andstoredif no key
is pressedfor approx.5 seconds.
keywhen switchingon.
H67 you areusing.Tochangethe setting,hold
ETSD40701
