YITAHOME
How to install toilet
1.To replace an older toilet, turn off water supply to toilet. Remove and drain
water supply line. Remove toilet hold-down bolts/screws. Remove toilet from
floor. Remove and discard old flange seal and hold-down bolts.Verify the center
of floor flange is at least 200mm/7.9" from back wall (Fig.1).
2.When installing a new floor flange, ensure that toilet mounting holes are locat-
ed at the correct angle (Fig.1).Floor flange must be secured to floor with a mini-
mum of four screws.Insert two supplied T-bolts into slots in floor flange( Fig.2).
3.Verify that floor flange seal is installed on the base of toilet.Carefully set toilet
over floor flange.Align holes in toilet base with T-bolts as toilet is lowered onto
floor flange.
4.Install floor mounting nuts onto T-bolts. When tightening, base should be
securely attached and flat against floor.Attach bolt covers onto nuts.
5.Connect water supply line to 1/2 inch water inlet and turn on water supply
line.( Fig.3)Flush toilet several times and check for leaks.
Back wall
(Fig.1)
(Fig.2)
5
YITAHOME
How to install handheld sprayer and water supply
T-Valve
Handheld Sprayer
1.Connect the two ends of the T-valve to the flexible sprayer hose and the 1/2
inch water supply hose. Then the other side of flexible sprayer hose connects to
the sprayer and the other side of 1/2 inch water hose connects to the toilet
2.Screw the sprayer hose and the sprayer head.
3.Put the sprayer in the holder
(Fig.3)
Water Supply Hose
6
Seal ring
Strainer
