YITAHOME
Product List
Toilet seat
T flush nozzle
Toilet base
Caution
1.Please always assemble according to the instruction.
2.Floor flange and 4 self-screws are included.
3.Press the foot pedal to touch the ground until opening the flush valve.
4.Ensure water supply pressure is no more than 0.4Mpa.
5.Hot water more than 40 degrees is forbidden.
Toilet lid
1/2 inch water inlet
Φ10mm mount-
ing hole
Drain valve
Floor mounting kit
Toilet pedal
Bolt and rubber
case
Seal ring
3
YITAHOME
Product and mounting dimension
Ref.
Description
390mm/15.4"
A
500mm/19.7"
B
233mm/9.2"
C
485mm/19.1"
D
380mm/15.0"
E
890mm/35.0"
F
The outside diameter of the toilet drain outlet: 95mm / 3.7";
The inner diameter of the toilet drain outlet: 87mm / 3.4"".
Description
Ref.
Minimum: 200mm/7.9"
G
H
Minimum: 200mm/7.9"
Minimum: 200mm/7.9"
I
170mm/6.7"
J
4
