EN352-4:2020 states that the minimum criteria (H, M and L)
must be greater than 85 dBA if the device is to be used in
environments with impulsive noise. For use in environments
with contunuous noise, EN352-4:2020 states that the minimum
level of the L criterion must be greater than 94 dBA, the mi-
nimum level of the M criterion must be greater than 96 dBA,
and the minimum level of the H criterion must be greater than
97 dB. ACE Alpha meets both criteria after rounding up to in-
teger values.
EN352-6:2020 - The calculated A-weighted sound level under
the capsule shall not exceed 82dB(A), taking into account at-
tenuation values. The 82dBA criterion level was -6.4 dbV or
478.6 millivolts. Detailed data for each subject is shown in the
table below. Enclosed you will find the overview:
Level to reach
82 dBA in dBV
Subject
L R
1 -6.6 -5.2
2 -5.4 -5.1
3 -3.3 -3.2
4 -3.1 -2.8
5 -5.9 -5.8
6 -7.2 -4.8
7 -4.4 -5.6
8 -3.3 -5.9
ACE_Alpha_Bedienungsanleitung_03-2022.indd 20-21 ACE_Alpha_Bedienungsanleitung_03-2022.indd 20-21
Mean -4.8 dBV
SD 1.4 dBV
Mean-SD -6.4 dBV
478.6 mV
20
VALUES ACCORDING TO ANSI:
Frequency in Hz
125 250 500 1000 2000 3150 4000 6300 8000
Subject
Means 13.4 17.8 25.7 33.7 34.3 38.4 39.2 38.6 36.7
Std. Dev. 3.5 2.4 2.9 3.3
NNR = 21 dB
The symbol on the product indicates that this product
should not be disposed of as household waste. Instead, the
product should be disposed of as an electronic product. By
disposing of this product correctly you will prevent negative
consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling.
For detailed information regarding this product, please con-
tact your local recycling facility, local waste collection service
or the product's point of sale.
21
3.1 3.8 4.1 3.1 2.6
CSA Class = B
Headband Force = 2.8 lbs
