Z - T E C H
(EN) CONSOLE
–
1
2
3
4
BLUETOOTH
1
Lights up when connected to APP.
HEART RATE
2
Built-in wireless heat rate receiver: compatible with
5.3KHZ or Bluetooth® 4.0 Heart Rate Monitor. (Heart
Rate Monitor not included). This icon flashes when
connection is established. The value is intended as
a guide and can not be used as medical data.
TIME
3
SPEED
4
WATT
5
RPM
6
RESISTANCE
7
Level: 1 – 50
CALORIES
8
DISTANCE
9
26 Z-TECH SPRINT BIKE
Z-TECH SPRINT BIKE (RVZT-10910) PRINT MANUAL V13 21.08.24.indd 26-27 Z-TECH SPRINT BIKE (RVZT-10910) PRINT MANUAL V13 21.08.24.indd 26-27
+
8
9
5 6 7
CONFIRM
Press the DIAL to confirm selection.
RESET
Press and hold the DIAL for 3 seconds to clear data
and return to the standby screen.
(-) DOWN
Rotate DIAL counter clockwise to decrease the
function value.
(+) UP
Rotate DIAL clockwise to increase the function value.
START/PAUSE
Bike automatically starts after sensing RPM,
otherwise it is paused.
COMPUTER PROGRAMS
POWER UP
When the power supply is connected to the machine, the console
will power on with a long beep sound. All segments of the LCD display
will light up for 2 seconds (Image 1) the wheel diameter 78.0" will be
displayed (Image 2), then it will enter Standby Mode (Image 3).
1. 2. 3.
QUICK START
In standby mode (Image 3) without setting the workout mode or target
value, the workout can be started directly by pedaling, and the console
will automatically start after sensing RPM.
MANUAL MODE
i. In standby mode (Image 3) press the dial to enter workout selection mode.
Rotate the dial to select Manual Mode (Image 4).
3. 4.
ii. To adjust the target values, first press the dial to select and switch
between TIME (Image 5)/DISTANCE (Image 6)/CALORIES (Image 7)
/PULSE (Image 8).
Rotate the dial to adjust the value, then press the dial to confirm the
setting and switch to the next value setting.
5. 7. 7. 8.
iii. After setting the values, the workout starts after pedaling. Each value is
displayed cyclically every 3 seconds (Images below). During the workout,
press the dial to switch and lock the workout value. When the workout value
is switched to TIME, the cycle value automatically starts.
iv. During the workout, rotate the dial to adjust the resistance level and its
value will be displayed. If it is not adjusted for 3 seconds, the previous
value will be restored to display.
v. When users stop pedaling, the console will be suspended, but the
workout values will automatically cyclically display.
vi. When the target value arrives, the console will be suspended and jump
back to the target set value to wait.
PRESET PROGRAMS (P01 – P12)
i. In standby mode (Image 3) press the dial to enter workout selection
mode. Rotate the dial to select Preset Program Mode (Image 9).
Rotate the dial, select the preset program P1 – P12 (Image 10), press the
dial to confirm, and enter the time setting (Image 5).
9. 10. 5.
ii. Rotate the dial to adjust the TIME value (this mode can only set TIME)
and press the dial to confirm the TIME setting.
iii. The workout starts after pedaling. During the workout, press dial to switch
and lock the workout value. When the workout value is switched to TIME,
it automatically begins cycling between values.
iv. During the workout, the resistance level will be automatically adjusted
according to the program, or rotate the dial to adjust the resistance level.
v. When you stop pedaling, the console will be suspended, but the workout
values will automatically cyclically display.
vi. When the target value arrives, the console will be suspended and jumps
back to the target set value to wait.
CONNECT TO A FITNESS APP
The console supports the Reebok, Kinomap, Pelton and Zwift APP. After
connecting with the Bluetooth the display is as follows.
POWER SAVING (ERP)
This product is fitted with a power saving Standby mode, which will activate
if the machine is inactive for a period of 5 minutes. To restart the machine,
simply press DIAL or pedal.
Off mode: 0.0W
Standby mode: 0.4W
