Product Introduction; Accessories - Tab R6 Benutzerhandbuch

IMPORTANT SAFETY INSTRUCTIONS
●
DO NOT：
1.Do not damage the power cord. Do not pull it when handling.
2.Do not use the machine when the power cord and plug are broken or the plug
gets loose.
3.Do not touch or plug and unplug it with wet hands.
4.Do not allow infants to touch the power plug.
5.Do not spray pesticides, hair colorants，lubricants and other liquid.
6.Do not inhale flammable and explosive substances such as cigarette ends.
7.Do not inhale oil gas heat or dry dust.
8.Do not disassemble, repair or transform it by oneself.
9.Do not use in dangerous situations such as rain water and strong wind.
10.Do not put the main machine in water or water the machine. in order to avoid
electric shock and fire.
11.Do not inhale dirt and dust with suspected infectious diseases
12.Do not use without a sewage bucket.
13.Do not use for purposes other than cleaning.
14.Do not lean or ride.
15.Do not use the machine within the reach of young children.
16.Do not allow children to use and play with it.
17.Do not use it outside.
18.Do not continue to use if the suction inlet is blocked.
19.Do not pull the power cord when plugging or unplugging it so as not to cause an
electric shock.
03

PRODUCT INTRODUCTION

●
Body：
1.Clean water tank 2. Cleaning brush 3. Button panel 4. Dirty water tank 5.Host machine
6. Hose 7. Water spray switch button 8.Hand retainer 9. Power switch 10. Bobbin winder base
11. Buckle 12. Lock
3
4
●
Accessories：
Standard brush WidePath brush
●
PRODUCT PARAMETERS：
230V 50Hz
Rated Working Voltage
1200W
Rated Power
13KPa
Vacuum Degree
≤80db
Noise
Clean Water Tank
1800ml
Capacity
Dirty Water Tank
950ml
Capacity
5m
Power Line Length
15s
Heating Time
2
7
1
8
5
11
6
T-shaped brush Self-clean brush Instruction
trockener und feuchter
Motor Type
Staubsauger Motor
≥300H
Motor Life
1.7m
Hose Length
Wa
terproof Level IPX4
4.2kg
Net Weight of Machine
5-50℃
Working temperature
320*226*327mm
Machine Size
≥300H
Heater Life Time
10
9
12
04
