NO. PART NO. DESCRIPTION
1 NE-461P01 Air Inlet
2 NE-461P02 Exhaust Deflector
3 NE-461P03 Motor Housing
4 NE-461P04 Lever
5 NE-461P05 Lever Pin
6 NE-461T06 O-Ring (2PCS)
7 NE-461P07 Valve Bushing
8 NE-461T08 O-Ring (2PCS)
9 NE-461P09 Valve Stem
10 NE-461P10 Spring
11 NE-461P11 Regulator
12 NE-461P12 O-Ring
13 NE-461P13 O-Ring
14 NE-461P14 Valve Screw
15 NE-461P15 Cover
16 NE-461P16 Ball Bearing 626ZZ
17 NE-461P17 Rear End Plate
18 NE-461P18 Cylinder
19 NE-461P19 Pin
20 NE-461P20 Spring Pin
21 NE-461T21 Rotor Blade (5PCS) 1 set
22 NE-461P22 Rotor
23 NE-461P23 Spring Pin
24 NE-461P24 Front End Plate
25 NE-461P25 Ball Bearing 608ZZ
26 NE-461P26 Washer
27 NE-461P27 Internal Gear
ltem No ： NE-461
QTY NO. PART NO.
1 28 NE-461P28 Ball Bearing 6001ZZ
1 29 NE-461T29 Gear (2PCS)
1 30 NE-461T30 Needle Bearing KT477
1
31 NE-461T31 Planet Pin (2PCS)
1
32 NE-461P32 Planet Cage
1 set
33 NE-461P33 Washer
1
34 NE-461P34 Ball Bearing 608ZZ
1 set
35 NE-461P35 Clamp Nut
1
36 NE-461P36 Needle Bearing 1212-HKQ
1
37 NE-461P37 Crank Shaft
1
38 NE-461P38 Driver Bushing
1
39 NE-461P39 Ratchet Housing
1
40 NE-461P40 Retaining Ring
1
41 NE-461T41 Washer (2PCS)
1
42 NE-461P42 Wave Washer
1
43 NE-461P43 Reverse Bushing
1
44 NE-461P44 Reverse Lever
1
45 NE-461P45 Ring
1
46 NE-461P46 Ratchet Ring
1
47 NE-461P47 Ring
48 NE-461T48 Ratchet Pawl Spring
1
1
49 NE-461P49 Ratchet Pawl (2PCS)
1
50 NE-461P50 Ratchet Yoke
1
51 NE-461P51 Wave Washer
1
52 NE-461P52 Spacer
1
53 NE-461P53 Retaining Ring
DESCRIPTION
(2PCS)
(2PCS)
QTY
1
1 set
1 set
1 set
1
1
1
1
1
1
1
1
1
1 set
1
1
1
1
1
1
1 set
1 set
1
1
1
1
