NO. PART NO.
1 NE-352P01 Plug
2 NE-352P02 Spring
3 NE-352P03 "O"-Ring
4 NE-352P04 Valve Stem
5 NE-352P05 "O"-Ring
6 NE-352P06 Valve Bushing
7 NE-352P07 Air Inlet Bushing
8 NE-352P08 Exhaust Deflector
9 NE-352P09 Muffler
10 NE-352P10 Throttle Lever
11 NE-352P11 Lever Pin
12 NE-352P12 Motor Housing
13 NE-352P13 Ball Bearing 696ZZ
14 NE-352P14 Rear End Plate
15 NE-352P15 Cylinder
16 NE-352P16 Pin
17 NE-352T17 Rotor Blade (5pcs)
18 NE-352P18 Rotor
19 NE-352P19 Front End Plate
20 NE-352P20 Ball Bearing 608ZZ
21 NE-352P21 Washer
22 NE-352P22 Ring Gear
ltem No ： NE-352
DESCRIPTION QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 set
1
1
1
1
1
NO. PART NO. DESCRIPTION
23 NE-352T23 Gear (3pcs)
24 NE-352T24 Gear Pin (3pcs)
25 NE-352P25 Gear Plate
26 NE-352P26 Lock Nut
27 NE-352P27 Needle Bearing
28 NE-352P28 Crank Shaft
29 NE-352P29 Drive Bushing
30 NE-352P30 Ratchet Housing
31 NE-352P31 Ratchet Yoke
32 NE-352P32 Reverse Button
33 NE-352P33 Washer
34 NE-352P34 Post
35 NE-352P35 Ratchet Pawl
36 NE-352P36 Spring Cap
37 NE-352P37 Spring
38 NE-352T38 Spring (2pcs)
39 NE-352T39 Steel Ball (2pcs) 1 set
40 NE-352P40 Ratchet Anvil
41 NE-352P41 Washer
42 NE-352P42 Retaining Ring
QTY
1 set
1 set
1
1
1
1
1
1
1
1
1
1
1
1
1
1 set
1
1
1
