Fnirsi LCR-P1 Benutzerhinweise Seite 16

Category
Field-Effect
Transistor
Unidirect-
ional SCR
Bidirect-
ional SCR
Capacitor
Resistor
Inductor
Battery
Infrared
Remote
Control
Decoding
*SCR:Silicon Controlled Rectifier
Range
·Gate capacitance Cg, drain current Id at
Vgs, forward voltage drop of protective
JFET
diode Uf.
·Id at Vgs, forward voltage drop of
IGBT
protective diode Uf.
·Threshold voltage Vt, gate capacitance
MIOSTET
Cg, drain-source resistance Rds, forward
voltage drop of protective diode Uf.
Turn-on
voltage < 5V,
Gate voltage
gate trigger
current < 6mA
Capacitance value, loss coefficient
25pF~100mF
Vloss, equivalent series resistance ESR.
Resistance value.
0.01Ω-50MΩ
Inductance value, DC resistance.
10uH-1000uH
Voltage value, polarity.
0.1-4.5V
Display user code and data code, and
NEC protocol
display corresponding infrared
infrared code
waveform.
Explanation
