Informazioni sulle normative
Conformità
Produttore
Informazioni di contatto e documentazione
del prodotto
Per informazioni di contatto o per scaricare la documentazione
del prodotto più recente, visitare firesecurityproducts.com.
Avvertenze sul prodotto e dichiarazioni di
non responsabilità
QUESTI PRODOTTI SONO DESTINATI ALLA VENDITA A E
DEVONO ESSERE MONTATI DA UN ESPERTO
QUALIFICATO. CARRIER FIRE & SECURITY B.V. NON PUÒ
GARANTIRE CHE LE PERSONE O GLI ENTI CHE
ACQUISTANO I SUOI PRODOTTI, COMPRESI I
"RIVENDITORI AUTORIZZATI", DISPONGANO DELLA
FORMAZIONE O DELL'ESPERIENZA ADEGUATE A
ESEGUIRE LA CORRETTA INSTALLAZIONE DI PRODOTTI
PER LA SICUREZZA E PER LA PROTEZIONE
ANTINCENDIO.
Per ulteriori informazioni sulle esclusioni di
garanzia e sulla sicurezza dei prodotti,
consultare il sito https://firesecurityproducts.com/
policy/product-warning/ oppure eseguire la
scansione del codice QR:
NL: Installatieblad
Afbeeldingen
Afbeelding 1: NC-DB-bedrading met eindelijnsweerstand
Afbeelding 2: NC-DBD-bedrading met actieve eindelijn
(1) IN5819 Diode tussen klemmen 1 en 2
Beschrijving
Dit installatieblad bevat informatie over de standaard
montagevoeten van de NC-serie die in de onderstaande tabel
worden weergegeven.
Model
Beschrijving
Standaard montagebasis voor conventionele
NC-DB-W
detectoren uit de NC-serie (wit)
NC-DB-B
Standaard montagebasis voor conventionele
detectoren uit de NC-serie (zwart)
Standaard montagebasis met geïntegreerde
NC-DBD-W [1]
diode voor conventionele detectoren uit de NC-
serie (wit)
8 / 12
Gulf Security Technology Co. Ltd.,
80 Changjiang East Road, QETDZ,
Qinhuangdao 066004, Hebei, Cina.
Rappresentante di produzione
autorizzato per l'UE:
Carrier Fire & Security B.V.,
Kelvinstraat 7, 6003 DH Weert, Paesi
Bassi.
Voor installatie op ruwe oppervlakken of over buizen kunt u het
NC-BA-SM-W accessoire voor opbouwmontage bestellen.
Compatibele detectoren
De montagebasis is compatibel voor gebruik met de volgende
conventionele detectoren uit de NC-serie.
Model
Beschrijving
NC-DPO-W
Conventionele optische detector (wit)
NC-DPM-W
Conventionele optische/warmtedetector (wit)
NC-DPM-B
Conventionele optische/warmtedetector (zwart)
NC-DPH-W
Conventionele warmtedetector (wit)
Installatie
WAARSCHUWING:
Gevaar van elektrocutie. Om persoonlijk
letsel of dood door elektrocutie te vermijden, dient u alle
stroomtoevoer af te sluiten en opgeslagen energie te ontladen
voordat u apparatuur installeert of verwijdert.
Let op:
Raadpleeg voor algemene richtlijnen met betrekking
tot systeemplanning, ontwerp, installatie, ingebruikname,
gebruik en onderhoud de norm EN 54-14 en de lokale
regelgeving.
De montagevoet installeren
Monteer de montagevoet op het oppervlak met behulp van 2 x
M4-schroeven (niet meegeleverd).
Bedrading
Bedraad de montagebasis zoals getoond in afbeelding 1
(standaardinstallatie met eindelijnsweerstand) of afbeelding 2
voor de diodebasis (BS 5839-1-installaties met actieve
eindelijnsafsluiting).
Aansluitingen voor elke aansluitklem worden hieronder
weergegeven.
Aansluitklem
Beschrijving
1
Lijn IN (+)
2
Lijn UIT (+), externe indicator (+)
3
Lijn IN/UIT (–)
4
Nevenindicator (–)
Specificaties
Aantal aansluitklemmen
Nevenindicatoraansluitklem
Toepassing
Polariteitsgevoelig
Aanbevolen kabel
P/N 3103026-ML • REV 001 • ISS 13JUN24
4
Ja
Gebruik binnenshuis
Ja
1,0 tot 2,1 mm² (17 tot 14 AWG)
afgeschermd of niet-afgeschermd
twisted-pair.
