Congratulations to the purchase of this Vonyx product. Please read this manual thoroughly prior to using the
product in order to benefit fully from all features. Keep the manual for future reference.
Carefully unpack the box upon receipt. Check the contents to ensure that all parts are present and have been
received in good condition. Notify the shipper immediately and retain packaging material if any parts appear
damaged from shipping or the package itself shows signs of mishandling. Save the package and all packaging
materials. If the product must be returned, it is important that the product is returned in the original factory box and
packaging.
1. Unfold the stand to make a "C" form.
2. Extend both stabilizers (a & b) from the bottom of the base framework.
3. Attach the base of the TV bracket to the base framework.
M8*40 carriage bolts
M8 hex nut
Ø24-8 washer
4. Attach the mount rails to the flatscreen TV (not included, sorry).
5. Install the flatscreen TV to the base TV bracket. Make sure the hooks on the mount rails line up correctly with the base
bracket).
2
ENGLISH
UNPACKING INSTRUCTION
ASSEMBLY INSTRUCTIONS
x4
x4
x4
