D+H TMA-1-D4-D12 Kurzanleitung Seite 2

Werbung

Anschluss – TMA
Nr.
Name
Beschreibung (als RM/RT-Linien)
X1.1
DO 2.3
keine Funktion
X1.2
DO 2.2
keine Funktion
X1.3
-
Bezugspotential (nicht mit P- verbinden)
X1.4
DO 1.3 (S)
Störungsausgang (RT-Linie 1), max. 50 mA
X1.5
DO 1.2 (A)
Alarmausgang (RT-Linie 1), max. 50 mA
X2.1
DO 1.1 (K)
Kontrollausgang (RT-Linie 1), max. 50 mA
X2.2
DI 1.1 (Z)
Reset-Eingang (RT-Linie 1)
X2.3
-
Bezugspotential (nicht mit P- verbinden)
X2.4
LINIE 1 (T)
RT-Linie 1, max. 50 mA
X2.5
FE
Funktionserde
X3.1
DO 2.1
keine Funktion
X3.2
DI 2.1
keine Funktion / Reset-Eingang BMA/BMZ
X3.3
-
Bezugspotential (nicht mit P- verbinden)
X3.4
LINIE 2 (R) RM-Linie 1, max. 50 mA
X3.5
FE
Funktionserde
X4.5
FE
Funktionserde
X4.4
LINIE 3 (R) RM-Linie 2, max. 50 mA
X4.3
-
Bezugspotential (nicht mit P- verbinden)
X4.2
DI 3.1
keine Funktion
X4.1
DO 3.1
keine Funktion
X5.5
FE
Funktionserde
X5.4
LINIE 4 (T)
RT-Linie 2
X5.3
-
Bezugspotential (nicht mit P- verbinden)
X5.2
DI 4.1 (Z)
Reset-Eingang (RT-Linie 2)
X5.1
DO 4.1 (K)
Kontrollausgang (RT-Linie 2), max. 50 mA
X6.5
DO 3.2 (A)
Alarmausgang (RT-Linie 2), max. 50 mA
X6.4
DO 3.3 (S)
Störungsausgang (RT-Linie 2), max. 50 mA
X6.3
-
Bezugspotential (nicht mit P- verbinden)
X6.2
DO 4.2
keine Funktion
X6.1
DO 4.3
keine Funktion
Nr.
Name
Beschreibung (als digitale Ein- bzw. Ausgänge)
frei konfigurierbarer digitaler Ausgang 2.3, max. 50 mA
X1.1
DO 2.3
frei konfigurierbarer digitaler Ausgang 2.2, max. 50 mA
X1.2
DO 2.2
Bezugspotential (nicht mit P- verbinden)
X1.3
-
frei konfigurierbarer digitaler Ausgang 1.3, max. 50 mA
X1.4
DO 1.3 (S)
X1.5
DO 1.2 (A)
frei konfigurierbarer digitaler Ausgang 1.2, max. 50 mA
X2.1
DO 1.1 (K)
frei konfigurierbarer digitaler Ausgang 1.1, max. 50 mA
X2.2
DI 1.1 (Z)
frei konfigurierbarer digitaler Eingang 1.1, 0 ... 28 V, - o. + aktiv
X2.3
-
Bezugspotential (nicht mit P- verbinden)
keine Funktion
X2.4
LINIE 1 (T)
Funktionserde
X2.5
FE
frei konfigurierbarer digitaler Ausgang 2.1, max. 50 mA
X3.1
DO 2.1
frei konfigurierbarer digitaler Eingang 2.1, 0 ... 28 V, - o. + aktiv
X3.2
DI 2.1
Bezugspotential (nicht mit P- verbinden)
X3.3
-
LINIE 2 (R) keine Funktion
X3.4
X3.5
FE
Funktionserde
Funktionserde
X4.5
FE
LINIE 3 (R) keine Funktion
X4.4
Bezugspotential (nicht mit P- verbinden)
X4.3
-
frei konfigurierbarer digitaler Eingang 3.1, 0 ... 28 V, - o. + aktiv
X4.2
DI 3.1
X4.1
DO 3.1
frei konfigurierbarer digitaler Ausgang 3.1, max. 50 mA
X5.5
FE
Funktionserde
X5.4
LINIE 4 (T)
keine Funktion
X5.3
-
Bezugspotential (nicht mit P- verbinden)
frei konfigurierbarer digitaler Eingang 4.1, 0 ... 28 V, - o. + aktiv
X5.2
DI 4.1 (Z)
frei konfigurierbarer digitaler Ausgang 4.1, max. 50 mA
X5.1
DO 4.1 (K)
frei konfigurierbarer digitaler Ausgang 3.2, max. 50 mA
X6.5
DO 3.2 (A)
frei konfigurierbarer digitaler Ausgang 3.3, max. 50 mA
X6.4
DO 3.3 (S)
X6.3
-
Bezugspotential (nicht mit P- verbinden)
frei konfigurierbarer digitaler Ausgang 4.2, max. 50 mA
X6.2
DO 4.2
frei konfigurierbarer digitaler Ausgang 4.3, max. 50 mA
X6.1
DO 4.3
2/4
TMA-1-D4-D12
Connection – TMA
No.
Name
X1.1
DO 2.3
X1.2
DO 2.2
X1.3
-
X1.4
DO 1.3 (S)
X1.5
DO 1.2 (A)
X2.1
DO 1.1 (K)
X2.2
DI 1.1 (Z)
X2.3
-
X2.4
LINIE 1 (T)
X2.5
FE
X3.1
DO 2.1
X3.2
DI 2.1
X3.3
-
X3.4
LINIE 2 (R) RM line 1, max. 50 mA
X3.5
FE
X4.5
FE
X4.4
LINIE 3 (R) RM line 2, max. 50 mA
X4.3
-
X4.2
DI 3.1
X4.1
DO 3.1
X5.5
FE
X5.4
LINIE 4 (T)
X5.3
-
X5.2
DI 4.1 (Z)
X5.1
DO 4.1 (K)
X6.5
DO 3.2 (A)
X6.4
DO 3.3 (S)
X6.3
-
X6.2
DO 4.2
X6.1
DO 4.3
No.
Name
X1.1
DO 2.3
X1.2
DO 2.2
X1.3
-
X1.4
DO 1.3 (S)
X1.5
DO 1.2 (A)
X2.1
DO 1.1 (K)
X2.2
DI 1.1 (Z)
X2.3
-
X2.4
LINIE 1 (T)
X2.5
FE
X3.1
DO 2.1
X3.2
DI 2.1
X3.3
-
LINIE 2 (R) No function
X3.4
X3.5
FE
X4.5
FE
LINIE 3 (R) No function
X4.4
X4.3
-
X4.2
DI 3.1
X4.1
DO 3.1
X5.5
FE
X5.4
LINIE 4 (T)
X5.3
-
X5.2
DI 4.1 (Z)
X5.1
DO 4.1 (K)
X6.5
DO 3.2 (A)
X6.4
DO 3.3 (S)
X6.3
-
X6.2
DO 4.2
X6.1
DO 4.3
Deutsch / English
Deutsch / English
Description (as RM/RT lines)
No function
No function
Reference potential (do not connect to P-)
Fault output (RT line 1), max. 50 mA
Alarm output (RT line 1), max. 50 mA
Monitoring output (RT line 1), max. 50 mA
Reset input (RT line 1)
Reference potential (do not connect to P-)
RT line 1, max. 50 mA
Functional earth
No function
No function / Reset input fire alarm system
Reference potential (do not connect to P-)
Functional earth
Functional earth
Reference potential (do not connect to P-)
No function
No function
Functional earth
RT Line 2
Reference potential (do not connect to P-)
Reset input (RT line 2)
Monitoring output (RT line 2), max. 50 mA
Alarm output (RT line 2), max. 50 mA
Fault output (RT line 2), max. 50 mA
Reference potential (do not connect to P-)
No function
No function
Description (as digital inputs/outputs)
Freely configurable digital output 2.3, max. 50 mA
Freely configurable digital output 2.2, max. 50 mA
Reference potential (do not connect to P-)
Freely configurable digital output 1.3, max. 50 mA
Freely configurable digital output 1.2, max. 50 mA
Freely configurable digital output 1.1, max. 50 mA
Freely configurable digital input 1.1, 0 to 28 V, active - or +
Reference potential (do not connect to P-)
No function
Functional earth
Freely configurable digital output 2.1, max. 50 mA
Freely configurable digital input 2.1, 0 to 28 V, active - or +
Reference potential (do not connect to P-)
Functional earth
Functional earth
Reference potential (do not connect to P-)
Freely configurable digital input 3.1, 0 to 28 V, active - or +
Freely configurable digital output 3.1, max. 50 mA
Functional earth
No function
Reference potential (do not connect to P-)
Freely configurable digital input 4.1, 0 to 28 V, active - or +
Freely configurable digital output 4.1, max. 50 mA
Freely configurable digital output 3.2, max. 50 mA
Freely configurable digital output 3.3, max. 50 mA
Reference potential (do not connect to P-)
Freely configurable digital output 4.2, max. 50 mA
Freely configurable digital output 4.3, max. 50 mA
