Dimplex Mk1 Bedienungsanleitung/Handbuch Seite 8

150
mm
(min)
'B'
MODEL Watts
B075E 750
C100E 1000
D150E 1500
E200E 2000
'B' 'D'
160
mm
(min)
7
'A'
75
mm (min)
A B
570mm 659mm 270mm
840mm 659mm 540mm
1105mm 659mm 805mm
1373mm 659mm 1073mm
Fig. 1
a
150
mm
(min)
305
Minimum front
clearance
C D
535mm
535mm
535mm
535mm
'C'
'A'
Fig. 1
b
Shelf
mm
(min)
300
mm
75
mm
Fig. 2
