2. FRAME TECHNICAL SPECIFICATIONS
FRAME SIZES
FRONT WHEEL SIZE
FRONT HUB
REAR WHEEL SIZE
REAR HUB
REAR AXLE
TOTAL WATER BOTTLE / RANGE EXTENDERS MOUNTS
BOTTOM BRACKET
REAR TRAVEL
REAR SHOCK
FRONT TRAVEL
SEATPOST DIAMETER
CHAINLINE
HEADSET
MAX CHAINRING
REAR BRAKE
MAX REAR TIRE WIDTH
3. SEAT POST INSERTION DEPTH
S / M / L / XL
29"
110mm x 15mm
29"
148mm x 12mm (BOOST)
L180mm M12 PITCH 1.0, HEAD DIAMETER 19mm
FOR L & XL SIZE BIKE FRAME: 2 B0TTLES (large + medium)
FOR M & S SIZE BIKE FRAME: 2 BOTTLES (large + small)
BSA 73
110mm
165 x 45mm TRUNNION, 30 x 8mm BOTTOM BUSHINGS
120mm
31.6mm (37mm seatpost clamp)
55mm
UPPER: IS52 1 1/8" , LOWER ZS56 BLOCKLOCK 1.5"
38T
POST MOUNT, DIRECT 160mm
61mm, 29 x 2.6"
FRAME SIZE
XL
L
M
S
MIN. (mm) MAX. (mm)
100 245
100 204
100 204
100 165
