Parts list

Part.Nr. Description
1 Upper Tube
2 Lower Tube
3 Socket (welded)
4 Net
5 Sleeve
6 Foam
7 Screw
8 Bolt M6X65
9 Nut M6
10 Washer M6
11 Plastic bushing
12 Pole cap
13 End cap
14 Tool
