TecTake 401212 Bersetzung Der Originalbetriebsanleitung

EN
C C
Step 1
A
Remove the folded up
D
bed and 2 end
bars(D.) from the
storage bag.
A A
C
B
A A
C
Step 4
Repeat steps 2 & 3 for the other side of the bed until all
legs (A.) are separated and pointing upward and both
parts (C.).are flat on the floor.
Step 6
Flip the Camping Bed over into the upright
position with the legs resting on the floor.
Slide the end bars (D.) into the canvas at
the head and foot of the bed. Lock into
position on the main frame using the holes
in part (D.).
ORIGINAL INSTRUCTION MANUAL
RETAIN FOR FUTURE REFERENCE
A
C
A
C
C
B
B
A
C
Step 7
with both ends slid into
the canvas and locked
into position, the Camping
D
Bed should now feel sturdy
and readty for use.
A
C
Step 2
Pull the leg(A.) up and
out while pulling part
(C.)down and out.
B
A A
Step 5
To open the Camping Bed, pull parts (A.) nd (B.) into and "X"
position until the lock.
401212
401213
401214
A Step 3
Part (C.)should sit flat on
the floor.Part (A.) must
C be pulled upright and
perpendicular to (C.).
A
B
A
WARNING
Please take care when folding and unfolding your Camp
Bed to avoid finger trapping.
A
B
