GRAVITY
COMPONENTS
Check The Eject Button for it's function
Troubleshooting:
a) The Eject Button is difficult to press
- Is the pull point set correctly? The pull point should be in place after a
maximum of 1 mm of free travel from The Eject Button.
- Is the seat post actuator running smoothly?
- Does the cable run smoothly in the casing?
- Is the casing laid in accordance with the required bending radii? A
bending radius that is too tight or a worn casing can make The Eject
Button difficult to operate.
b) The seat post cannot be extended or retracted
- Is the pull point set correctly? The pull point should be in place after a
maximum of 1 mm of free travel from The Eject Button.
c) The seat post comes out again on its own
- The cable has too much pre-tension.
Benutzerhandbuch + Montageanleitung
User manual + assembly instructions
12
