1 - SAFETY WARNINGS
ATTENTION! Before starting the installation, carry out the following analyzes and
checks: verify that the individual devices intended for automation are suitable for
the system to be created. In this regard, check the data reported in paragraph 2
"Technical characteristics" with particular attention. Do not carry out the installa-
tion if even one of these devices is not suitable for use. Do not carry out modifica-
tions to any part of the equipment other than those foreseen in this Manual; operations
of this type can only cause malfunctions. The manufacturer declines all responsibility
for damage resulting from arbitrarily modified products. Prevent parts of the equipment
components from being immersed in water or other liquid substances; during installation,
prevent liquids from penetrating inside the devices present. If liquid substances pene-
trate inside the parts of the automation components, immediately disconnect the power
supply and contact the Key Automation Assistance Service. Using the automation in
such conditions can cause dangerous situations. Do not place the various components
of the automation near heat sources or expose them to open flames; such actions may
damage them and cause malfunctions, fire or dangerous situations.
ATTENTION! The equipment must be disconnected from the power source during
cleaning, maintenance and replacement of components.
Provide a disconnection device in the equipment's power supply network with a con-
tact opening distance that allows complete disconnection in the conditions dictated by
overvoltage category III; for the connection of rigid and flexible pipes or cable glands,
use fittings compliant with the IP55 protection degree or higher; the electrical system
upstream of the automation must comply with current regulations and be carried out in
a workmanlike manner.
KEY AUTOMATION S.r.l. reserves the right to modify these instructions if necessa-
ry, these and/or a higher version can be found on the website www.keyautomation.
com
2 - INTRODUCING THE PRODUCT
VIP2, with the QUADRO ambient light sensor and the Key Automation garage door auto-
mations, allows the automatic control of additional LED lights outside or inside the door.
The Night Light System turns on or off, based on the level of ambient light, the lights
after 15 minutes of exceeding the set threshold. This behavior avoids false switching
on or off due to external light sources such as car headlights. VIP2, combined with the
QUADRO light sensor, can also be used with the Key Automation BOXLEDXS2 power
supply and the LED lights will switch on based on the ambient light level. The lights can
also be activated manually, regardless of the ambient light level, by connecting a switch
to the LED_V input. The VIP2 equipment, when powered by the control unit in the garage
motor, via the QUADRO ambient light sensor, automatically activates up to 30W of Key
Automation LED lights during the night. If connected to a Key Automation control unit,
the lights can be activated during the manoeuvre, regardless of the ambient light level
or by remote control. The behavior of the LED lights can be managed by acting on the
parameters of the control unit itself. NOTE: to check the available operating modes, refer
to the manual to which VIP2 is connected.
CODE DESCRIPTION
VIP2 Key Automation LED light control device
TECHNICAL SPECIFICATIONS
power supply
maximum led power
protection rating
operating temperature
dimensions (L-D-H)
ELECTRIC CABLE TECHNICAL SPECIFICATIONS
connection cable
quadro 1 x cable 2 x 0,5 mm
led 1 x cable 2 x 0,75 mm
viper led / VIP2 1 x cable 3 x 0,75 mm

3 - PRELIMINARY CHECKS

WARNING - before installing the product, perform the following checks and inspections:
• Position the QUADRO night-time sensor in a sunny area
• Position VIP2 in a sheltered are in the building
• Use electrical connections suitable for the currents required
• Check that the power supply conforms to the values in the technical specifications
4 - CUSTOMIZATION INSTALLATION
POWER VOLTAGE SETTING
The procedure sets the type of power supply to which VIP2 is connected: 24VDC stabi-
lized power supply or Key Automation motor control unit (HALO, CT10324, CT20324).
PH. DESCRIPTION
1 Press and kepp pressed the button S1
2 L1 LED turns on; keep the S1 button pressed
After about three seconds the L1 LED turns
3
off; release button S1
LED L1 starts to flash slowly, press:
at the third flash for operation with Key Automation engine control unit (default
4
value);
at the fourth flash for operation with a stabilized 24Vdc power supply.
NOTE: to check the correct setting, briefly turn off VIP2 and turn it back on if:
- LED L1 flashes once and is set for operation with Key Automation control units
- LED L1 flashes twice and is set for operation with a 24Vdc stabilized power supply
VIP2
24/32 Vdc
30W
IP3X
-20+50°C
85-40-25 mm
maximum permitted limit
10 m
2
20 m
2
5 m
2
EXAMPLE
x 1
x 1
> 3sec
ADJUST LED BRIGHTNESS
The procedure modifies the level of light emitted.
PH. DESCRIPTION
1 Briefly press the S1 button once
2 LED L1 emits a short flash
Immediately after the first flash, press and
3
hold button S1 (the LED remains off)
After approximately three seconds, release
4
the S1 button
The L1 LED starts to flash slowly, press the S1
button to select the light level:
1st flash, level 1 low brightness
2nd flash, level 2
5
3rd flash, level 3 medium brightness – default
value
4th flash, level 4
5th flash, level 5 high brightness
INTERVENTION THRESHOLD ADJUSTMENT
The procedure modifies the ambient light level which causes the lights to change state
(from deactivated to active and vice versa).
PH. DESCRIPTION
1 Briefly press the S1 button twice
2 LED L1 emits two short flashes
Immediately after the second flash, press
3
and hold button S1 (the LED remains off)
After approximately three seconds, release
4
the S1 button
The L1 LED starts to flash slowly, press the
S1 button to select the intervention threshold
of the ambient light sensor:
1st flash, level 1 activation with low ambient
5 brightness
2nd flash, level 2 activation with low ambient
brightness – default value
3rd flash, level 3 activation with high ambient
brightness

5 - TESTING AND COMMISSIONING

The system may be put into operation after testing by a qualified technician, who must
perform the tests required by the relevant standards in relation to the risks present, to
check that the installation complies with the relevant regulatory requirements.
6 - DISPOSAL
WARNING! Packaging components (cardboard, plastic, etc.), duly separated, must
be placed in the appropriate bins. Device components such as electronic boards,
metal parts, batteries, etc. must be separated and differentiated. For the methods
of disposal, the rules in force in the place of installation must be applied. DO NOT
DISPOSE IN THE ENVIRONMENT!
EXAMPLE
x 1
x 1
> 3sec
+ + + +
EXAMPLE
x 2
x 2
> 3sec
+ +
