t c :
ablE of ontEntS
1) INTRODUcTION.................................................................25
2) SPEcIFIcATIONS...........................................................25
3) PAcKAGE cONTENT.................................................................26
4) OVERVIEW LED INDIcATIONS / bUTTONS..................................26
5) OVERVIEW REAR PANEL...........................................................28
6) REMINDERS...................................................................29
7) AbOUT RAID...........................................................................30
8) cAUTIONS.....................................................................32
9) QUIK INSTALLATION GUIDE......................................................32
10) hDD INITIALIZING AND FORMATTING.......................................35
11) TROUbLE ShOOTING................................................................40
12) FAQ..............................................................................42
13) cONTAcT & TEchNIcAL SUPPORT...........................................45
FANTEC QB-X2US3R 2-BAY 3.5" RAID
1) I
ntroDuctIon
Secure your data on the FANTEc Qb-X2US3R with space for two SATA
hard drives in one housing. With various RAID Level (0, 1, JbOD, and
bIG) the Qb-X2US3R provides various settings for data security
and data redundancy. All drives can be displayed separately and hence
controlled separately, easily switched, replaced and independently from
manufacturer or capacity expanded. The SUPERSPEED USb 3.0 interfa-
ce provides high data tranfser up to 5Gbps. With full SATA III 6G support
and the new UASP transfer Protocol, the device can reach a speed up to
70% higher than conventional USb 3.0 enclosures. The 60mm fan can
be used in automatic mode with built-in thermal sensor or by manual
mode with 3 levels of speed. The energy saving feature turns off the
FANTEc Qb-X2US3R automatically when the Pc is shut down.
2) S
pEcIfIcatIonS
Device Support:
Internal Interface:
External Interface:
Power Supply:
Material:
Dimensions (W/D/h):
OS Support:
Operation Environment:
Smart fan with 2 modes
(auto / manuel) and
3 levels of speed:
FANTEC QB-X2US3R 2-BAY 3.5" RAID
24
3.5" SATA I/II/III hard Drives
SATA 6 Gbps
USb 3.0 Superspeed (Downwards
compatible to USb 2.0 & 1.1)
Ac Adapter, 12V / 3A
High quality Aluminum
92.6mm x 208.8mm x 160mm
Windows® 7, 8, 8.1,10
Mac OS X 10.8 or later, Linux
Temperature 0 ~ 50°c
humidity 90 % Rh
Level 1: < 45°c 1,200 ~ 1,800rpm
Level 2: 45 ~ 54°c 1,800 ~ 2,500rpm
Level 3: > 55°c 2,500 ~ 3,500rpm
