Features
Top Panel
3
4
5
6
7
8
1.
Keybed: This 25-note keyboard is velocity-sensitive and, along with the Octave Down /
Up buttons, can control a ten-octave range. You can use the keys to access certain
additional commands, as well. Hold down the Arpeggiator On/Off button and press a
key to set the Arpeggiator parameters. Press the Keys button and turn the encoder to
change sounds triggered from the keys.
2.
Drum Pads: The pads can be used to trigger drum hits or other samples in your
software. The pads are velocity-sensitive, which makes them very responsive and
intuitive to play. When the Drums button is pressed, you can turn the encoder to change
sounds on the drum pads. Access one of the 8 Favorites (a combination of a sound on
the keyboard and a sound on the drum pads) by pressing and holding the Favorites
button and tapping a drum pad.
3.
X-Y Controller: Use this 4-axis thumbstick to send MIDI pitch bend messages or send
MIDI CC messages.
4.
Arpeggiator On/Off: Press this button to turn the Arpeggiator on or off. Pressing it
during a latched arpeggio will stop the arpeggio. Hold down this button and press the
corresponding key to set the following parameters:
•
Time Division: 1/4 note, 1/4 note triplet (1/4T), 1/8 note, 1/8 note triplet (1/8T), 1/16
note, 1/16 note triplet (1/16T), 1/32 note, or 1/32 note triplet (1/32T).
•
Mode: The mode determines how the arpeggiated notes are played back.
Up: Notes will sound from the lowest to the highest.
o
Down: Notes will sound from the highest to lowest.
o
Excl (Exclusive): Notes will sound from the lowest to the highest, and then back
o
down. The lowest and highest notes will sound only once at the directional change.
Incl (Inclusive): Notes will sound from the lowest to the highest, and then back
o
down. The lowest and highest notes will sound twice at the directional change.
Order: Notes will sound in the order they were pressed.
o
Rand (Random): Notes will sound in random order.
o
