FASTENING THE SIDE TO THE ADULT BED (fig. 16)
Place the cradle next to the adult bed, ensuring that the lowered side is next to the mattress and the
mattress of the adult bed is aligned with or higher than the height of the lowered side. If it is necessary
to adjust the cradle to the required height, see the section entitled "ADJUSTING THE HEIGHT OF THE
NANNA CO-SLEEPING".
To attach the "Nanna co-sleeping" to the bed, use the supplied safety straps (Ax2 , Bx2) and:
• Hook the short straps "A" to the front support bar, as shown in fig. (1), (2), (3).
• Hook buckle A to buckle B, as shown in fig. (3).
• Pass the free flap of the safety strap around the adult bed rail, or the mattress support bed base or
slatted frame, as shown in the figure 4, and hook buckle C1 to buckle C2. Repeat the operation with
the second safety strap.
• Tension both straps to secure the product firmly to the adult bed.
• Wrap the free end of the strap and lock it. Make sure that the free strap is completely out of the child's
reach.
• Ensure that you have performed the required steps correctly.
• Apply the brake on all wheels.
(iCrib "BOX" version)fig. 17
• Adjust the height of the "Nanna CO-SLEEPING" to position 1, lowest, see paragraph "ADJUSTING
THE HEIGHT "Nanna CO-SLEEPING "
• Pull out the mattress (a-b).
• Leave the recliner fully raised and latched with the zips closed.
• Open the zip at the bottom, along the inside perimeter.
• Using the inside handles, lift the bottom about 10/15 cm (c).
• Recline one side of the bottom, pulling the guides out of the hooking seats and lower it slowly, repeat
the operation on the opposite side (d).
• Lower the bottom completely to the floor (e).
• Place the mattress inside (f)
• Fold down the 4 support feet (g).
• Wrap the two straps around the bottom reinforcement bar (h).
• Apply the wheel brake
• Actuate the swinging movement lock, see section "MOVEMENT LOCK".
