TOP REMOVABLE
REFRIGERATION TABLE TOP 54 CM
HOW TO REMOVE THE TOP BEFORE TO PLACE THE
APPLIANCE IN BUILT IN POSITION
Operation n° 1
To dismount the 2 screws on the back side of the product
Operation n° 2
screws
To lift up from rear the top, and remove it from front fixation
Operation n° 3
To dismount the 10 screws on the front plastic frame and metal
hinge
Operation n° 4
screws
To move out the hinge and the plastic frame
Operation n° 5
screws
To replace and to refit the metallic hinge with 2 screws
