USER MANUAL
InLine® Audio Converter Digital to Analog Input Toslink or RCA
Output 2x RCA Stereo
GENERAL INFORMATION
Validity:
This user manual applies to the following product:
• 65002 InLine® Audio Converter Digital to Analog Input Toslink or RCA Output
2x RCA Stereo
Manufacturer:
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
service@inline-info.com
Date: 07 / 2024
CONTENT OF DELIVERY
1x InLine® Audio Converter Digital to Analog
1x Power supply 5.0 V DC / 1.0 A
1x User manual (German/English)
Please check the content of delivery for completeness. If individual components
are missing, please contact your dealer.
TECHNICAL FEATURES
• Input: S/PDIF or Toslink
• Incoming Bit Stream: 24-Bit S/PDIF
• Output: 2 RCA l/r (white/red)
• Sampling rate of 32 / 44.1 / 48 and 96 kHz
• Provides electromagnetic-noise-free transmission
• Easy installation and operation
• Frequency response: <0.5dB
• Signal to noise: ≥109dB
• Degree of separation: <-100dB
• Dimensions (LxWxH): 63.6 x 41.3 x 26.4 mm
• Weight: 75 g
• Operating temperature: 0°C to +40°C
• Operating humidity: 20 % to 90 % RH (no condensation)
• Storage temperature: -10°C to +80°C
• Storage humidity: 5 % to 90 % RH (no condensation)
Power supply unit:
• Input voltage: 100-240 V AC
• Input AC input frequency: ~50/60Hz, 0.3 A max.
• Output voltage: 5.0 V DC
• Output current: 1.0 A
• Output power: 5.0 W
• Average active efficiency: 74.55%
• No-load power consumption: 0.07 W
INTENDED USE
This Digital to Analog Audio Converter is designed for either home or professional
audio switching. It converts Coaxial or Toslink digital audio signals to analog L/R
audio and available for connection to an external device such as an amplifier via
standard RCA-style jacks.
GENERAL WARNINGS
• Do not expose the InLine® Audio Converter to excessive heat.
• Protect from dust and moisture.
• Be careful not to crush, bend or damage the cables with sharp edges when
using the product.
• Do not expose the product to direct sunlight, strong vibrations, vapors and
solvents, and avoid high humidity or moisture.
• Never plug in or unplug power supplies with wet hands.
• When moving the cables, always make sure that no one can trip over them.
There is a risk of injury.
• During thunderstorms, unplug the power supply from the wall outlet.
IMPROPER USE
The following is considered improper use in the sense of foreseeable misuse:
• Use the device indoors only, the device is not suitable for outdoor applications.
• Do not disassemble the InLine® Audio Converter.
MAINTENANCE AND CLEANING
Clean the InLine® Audio Converter with a dry, velvety cloth.
Do not use water or other cleaning fluids that may damage the electronics.
CONNECTION IMAGE
CONNECT THE DEVICE
Before installation,please make sure all devices you wish to connect have been
turned off.
1. Connect the audio source device to the Converter using appropriate Toslink or
Coaxial cables.
2. Connect the A/V Receivers or Amplifiers to the Converter using appropriate
L/R cable.
3. Insert the DC side of 5V power supply into the converter and then connect the
AC side of the power supply into the wall outlet.
When connected to the Toslink and Coaxial cables at the same time,the product
will give priority to Toslink input.
DISPOSAL
Electrical and electronic devices as well as batteries must not be disposed
of with household waste. The consumer is legally obliged to return electrical
and electronic equipment and batteries at the end of their service life to the public
collection points set up for this purpose or to the point of sale.
SIMPLIFIED EC DECLARATION
OF CONFORMITY
The Manufacturer / Importer:
INTOS ELECTRONIC AG
Siemensstrasse 11
35394 Giessen
hereby declares that this InLine® Audio Converter is in conformity with the direc-
tives 2014/30/EU, 2014/35/EU as well as 2011/65/EU incl. supplement 2015/863/
EU and the ERP Regulation - 2019/1782 Regulation from Ecodesign Directive
2009/125/EU.
The full part of the EU Declaration of Conformity is available at the
following web address:
https://www.inline-info.com/en/downloadcenter
DISCLAIMER
2nd edition English 07 / 2024
Documentation © 2024 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or by any
means, electronic, mechanical or chemical, without the prior written permission of
the publisher.
It is possible that this manual may still contain typographical defects or misprints.
However, the information in this manual will be checked regularly and corrections
will be made in the next edition. We accept no liability for errors of a technical
or printing nature and their consequences. All trademarks and industrial property
rights are acknowledged. Changes in the sense of technical progress can be made
without prior notice. Our products, including packaging, are not toys, they may
contain small parts and sharp objects.
Please keep away from children.
