INSTRUCTION MANUAL I ENGLISH
OPERATION
- Screw the Muted RTA onto a mod.
- Turn the tank counterclockwise and simultaneously pull upwards
to remove it from the base.
- Prepare a coil (insert the wire under the coil placement aid
– we recommend a coil with an inner diameter of 2.5 mm) and place the coil
placement aid on the fixture. Insert the wire ends into the designated slots and
tighten the post screws. Remove the wire ends – they must not come into
contact with any other components.
✓
- The pre-installed 0.9 mm airflow inserts can be replaced at any time with
the tank removed.
18 English
✗
When reattaching the tank, ensure that the logos on the tank
NOTE:
The 510 positive pin is not adjustable. If you wish to extend the positive pin,
you can easily do so by adding an extra O-ring. This O-ring is included in the
spare parts pouch.
Vaping
1
(Liquid control open)
Tank removal
2
Filling and transport
(Liquid control closed)
align with the bayonet locks on the deck.
