Instructions
1 Remove the slot cover
by turning the screw
counter clockwise.
2 Attach the carrier
bracket to the media
converter.
First, unscrew the two
screws on the side of
the media converter
housing, as indicated by
the circles.
3 Next, use these screws
to affix the bracket to
the media converter
housing. You will
need a screw driver
with a Phillips head
("crosshead").
Note: You need to attach
the bracket to the side
of the media converter
on which the power
plug is located. Check
the rear of the media
converter housing to
find out on which side
the carrier brackets need
to be connected to.
Installation
3
