d) Use a dust collection system when possible. Seal the work
area with plastic. Do not track paint dust outside of the work
area.
e) Thoroughly clean the area when the paint sanding project
is completed
Product Familiarisation
1. Belt Tracking Knob
2. Belt Release Lever
3. Workpiece Stop
4. Spindle Lock Knob
5. Workpiece Stop Wing Nut
6. Fixed Table
7. Throat Plate Storage
8. Table Angle Knob
9. Table Angle Gauge
10. Table Angle Notches
11. Bench Mounting Holes
12. OFF Switch
13. ON Switch
14. Washer Storage
15. Drum Storage
16. Tilting Table
17. Belt Sander
18. Dust Extraction Port
19. Table Angle Knob
20. Throat Plate Storage
21. Wrench Storage
22. Rear Storage
23. Belt Sanding Unit
24. Sanding Belt
25. Sanding Sleeves (5 sizes)
26. Throat Plates (5 sizes)
27. Spindle Nut
28. Spindle Washers
29. Table Insert
30. Wrench
31. Sleeve Drums (4 sizes)
32. Spindle
33. Spindle Knob
34. Dust Port Adaptor
35. Drive Adaptor
Intended Use
Mains-powered bench-mounted sanding machine that can be
fitted with either a rotating and height oscillating sanding sleeve
drum or a sanding belt unit. For sanding curved and straight
surfaces on intricate as well as larger workpieces. Tilting front
section table enables edge work, typically chamfering.
Not suitable for commercial use.
The tool must ONLY be used for its intended purpose. Any use other
than those mentioned in this manual will be considered a case
of misuse. The operator, and not the manufacturer, shall be liable
for any damage or injury resulting from such cases of misuse. The
manufacturer shall not be liable for any modifications made to the
tool, nor for any damage resulting from such modifications.
Unpacking Your Tool
• Carefully unpack and inspect your product. Fully familiarise
yourself with all its features and functions
• Ensure all parts of the product are present and in good
condition. If any parts are missing or damaged, have such parts
replaced before attempting to use this product
Before Use
WARNING: Ensure the tool is disconnected from the power
supply before attaching or changing any accessories, or making
any adjustments.
Bench Mounting
If the spindle sander is to be used in a permanent position, it is
recommended that you secure it to a rigid work surface.
• Use the Bench Mounting Holes (11) in the base as a template
to mark and drill four holes in your intended mounting surface
(i.e. workbench). Secure the spindle sander into position using
large bolts, washers and nuts (not supplied) (Fig. I)
• If the spindle sander is intended to be more portable, fix a
board to the base which can be easily clamped and removed
from various mounting surfaces
• If using bolts make sure they are long enough to penetrate the
workbench or board sufficiently for a secure fix
Note: Use nylon insert lock nuts or spring washers in the fixings to
prevent vibration from loosening the fixings.
Note: Never use bolts that require force to push through the
Bench Mounting Holes as these may crack the plastic body, as will
over-tightening the fixings.
Dust Extraction
It is recommended that the spindle sander is used with a dust
extraction system for a cleaner and safer work environment.
1. Attach the hose from the dust extraction system to the Dust
Extraction Port (18) and ensure it is secure
2. For greatest efficiency, activate the dust extraction system before
turning on the spindle sander
Inserting the Drive Adaptor
1. Insert the Drive Adaptor (35) on to the Spindle (32) (Fig. II)
Note: Ensure the Drive Adaptor is inserted correctly, with the flat
side facing up. One end of the locating hole in the Drive Adaptor
has 2 flat edges. These should locate with the corresponding flat
sides on the bottom of the Spindle.
Belt Sander Mode
1. To remove the spindle sander components, unscrew the Spindle
Nut (27) using the Wrench (30) and remove the fitted Spindle
Washer (28), Sleeve Drum (31), Throat Plate (26) and
Table Insert (29)
2. Store the spindle sander components into the built-in storage
areas of the main body; these are Washer Storage (14), Drum
Storage (15), Throat Plate Storage (7 & 20) and
Rear Storage (22)
3. Check the Drive Adaptor is correctly located onto the Spindle
(Fig. II) (See "Inserting the Drive Adaptor" section)
4. Slide the Belt Sander (17) over the Spindle (32) so that it fits
into the recess of the Fixed Table (6). Ensure the Belt Sander
fully engages with the Drive Adaptor (35), and secure in
position with the Spindle Washer and Spindle Knob (33)
If required for operation, fit the Workpiece Stop (3) using the
Workpiece Stop Wing Nut (5)
EN
9
