TECHNICAL SPECIFICATION
Working voltage: 380V~480V AC (3 phases)
Operating current: 32A (3 phase) max
Overvoltage protection: 265V (1 phase voltage)
Undervoltage protection: 175V (1 phase voltage)
Overcurrent protection: ≥110% rated current
Leakage protection: AC/A+DC6mA
Ground fault protection: Yes
Lightning protection: Yes
Water resistance: IP67 Type 2 connector / IP54 charger / IP44 CEE industrial plug
LCD: 2.8" display
Power supply: 22KW Max
Operating temperature: -25°C~+55°C
Operating humidity: 5% ~ 95%
Working altitude: <2000m
Communication mode: Wifi / Bluetooth / TUYA
Connector type: Type 2 / Mode 2
Overheat protection: Yes
Cable harness: 5*6mm2 + 1*0.25mm2
Cable length: 5m
GENERAL INSTRUCTIONS
This manual contains important safety instructions, please read before using
the charger. Please keep these instructions. This manual must be considered an
integral part of the device and must always be available to all who come into
contact with the device. The manual must always be attached to the device, even
when handing it over to another user.
Intended use
This product is intended for occasional CHARGING of electric vehicles. It is not
intended for permanent charging.
SPECIFICATION
Chargers for electric cars generally do not require daily or regular maintenance.
Wipe the charger with a soft dry cloth.
Do not use water, caustic chemicals or aggressive cleaning agents. Disconnect
the device from AC power before cleaning.
Make sure the EV charger is stored in a dry place.
WARNING
Please read all instructions in this manual before using this product.
Children should be supervised when near the charger while it is plugged in. Do
not place the EV charger near explosive, flammable materials, chemical fumes, or
potentially hazardous materials.
The product must be grounded. Should it fail or malfunction, grounding provides
a path of least resistance for electrical current, reducing the risk of electric shock.
The device detects the presence of proper grounding and will not work if it is
disconnected.
-Do not use the charger with a damaged output cable, charger connector or
module.
-Do not disassemble the internal components of the EV charger without
permission, this will void the warranty.
-Always position the charger output cable so that it cannot be walked on,
stepped on or tripped over, damaged or otherwise stressed.
- Unplug the charger before cleaning it. To clean the charger, wipe it with a clean
cloth dampened with water or a mild solution of detergent suitable for use on
automotive parts. Do not use chemicals or solvents.
-Do not submerge the control box or charging connector in water.
USER MANUAL
Immax NEO LITE travel charging station
for electric cars EV/PHEV AC Type 2 22kW Tuya
PRODUCT DIAGRAM
QUICK CHARGING GUIDE
1. Plug the charger into
the socket correctly
LIGHT INDICATOR
charging
connector
32A adapter
CEE on Shuko 1
phase
cable 5m
2. Double-click to set
the required current
(amps).
Green on - Connected - Charger connected
Green Blinking - Connected - The charger is properly connec-
ted to your vehicle
Blinking Blue - Charging - The charger is charging your vehicle
Blue - Full Charge - Your vehicle is fully charged
Manufacturer and importer: IMMAX, Pohorie 703, 742 85 Vresina, EU
Designed in the Czech Republic, made in China
NSE003
LCD
display
32A red
industrial plug
indicator light,
function button,
power button
3. Connect to the
vehicle
