This device may not be operated in the vicinity of medical facilities (for example, dialysis machines).
When in operation, this device may affect the function of picture display terminals, such as computer
monitors, etc.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, etc.
INSTALLATION
Remove all packaging material.
Install your plasma-disc on a plane ground. Fix the standing foot and make sure that the fixation is locked on
both sides. Fixate the front fixing points.
Connect your plasma-disc to the mains using the power-adapter.
OPERATION
After you connected the effect to the mains, the plasma-disc starts running.
Set the mode-selector to Manual. Turn the Pattern-control to the maximum right position. Adjust the
sensitivity via the Sensitivity-control. As soon as you touch the screen, the device will react in accordance with
the settings you made.
Set the mode-selector to Auto. The flashes are now sound-controlled. You can adjust the microphone
sensitivity via the Sensitivity-control. Turn the Pattern-control to the right and watch how the patterns change.
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no servicable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only in
order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Version:
Power supply (
via enclosed power supply unit
Power consumption:
Sound-control:
Maximum ambient temperature T
Max. housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Diameter:
Weight:
Please note: Every information is subject to change without prior notice. 10.09.2012 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
Diameter 25 cm
): 230 V, 50 Hz
14 W
via built-in
microphone
: 45° C
a
(steady state): 90° C
C
0.5 m
0.5 m
25 cm
1.8 kg
Diameter 30 cm
230 V, 50 Hz
16 W
via built-in
microphone
45° C
90° C
0.5 m
0.5 m
30 cm
2 kg
8/8
Diameter 40 cm
230 V, 50 Hz
18 W
via built-in
microphone
45° C
90° C
0.5 m
0.5 m
40 cm
3 kg
00072030.DOC, Version 1.4
