IBEA 25STL Gebrauchsanweisung Seite 14

GB
ENGLISH
1. Ignition switch (stop).
2. Throttle trigger.
3. Throttle advance.
4. Automatic choke.
5. Fuel tank.
6. Fuel cap.
7. Primer (fuel air purge).
8. Starter grip.
14
3. DESCRIPTION
10
14
12
1
11
3
2
9. Air filter.
10. Front handle
11. Safety operator protection
12. Harness hanger
15. Blade safety guard.
17. Gear Head.
18. Nylon head.
19. Transmission tube
8
7
9
5
6
4
Only for MULTIFUNCTION model:
13. Transmission tube
14. Coupling sleeve
16. Brushcutter attachment
ATTACHMENTS ON OPTION:
A. BENT PRUNER (35°)
B. HEDGE TRIMMER
C. STRAIGHT PRUNER
