Contracor BlastRazor Z-25 Bedienungsanleitung Seite 5

Table. 2.1.
Article
10400300
10400401
Fig. 2.1.
1 — cover
2 — screen
3 — machine tank
4 — pressurizing ball valve
5 — upper air line ball valve
6 — moisture and oil separator
CONTRACOR BlastRazor Z-25, BlastRazor Z-50
®
Model Description, configuration
BlastRazor Abrasive Blasting Machine, 25 l,
Z-25 screen,
cover,
filter, oil and moisture separator CAF-0,
abrasive metering valve FSV.
BlastRazor Abrasive Blasting Machine, 50 l,
Z-50 screen,
cover,
filter, oil and moisture separator CAF-0,
abrasive metering valve FSV.
7 — lower air line ball valve
8 — abrasive blasting hose
9 — Operator Helmet
10 — nozzle holder
11 — nozzle
12 — breathing air hose
13 — breathing air filter
10400300/10400401 5
