MSI FORCE PRO WIRELESS Kurzanleitung Seite 4

1� Left / Right Thumbsticks
2� Directional Pad (D-Pad)
3� Top Cover
4� Power / Battery Indicator LED
5� Share Button
6� ABXY Buttons
7� Menu Button
8� Status LED
9� Xbox Button
10� View Button
11� Bumpers (LB & RB)
12� Triggers (LT & RT)
Connect to PC
Power on the Controller by pressing the Xbox Button.
• Wired Connection: Connect to PC with the USB-C cable until the Status LED turns solid
WHITE.
• 2.4 GHz Wireless Connection: First, toggle the Wireless Mode Switch to
Wireless USB Dongle into an available USB port, until the Status LED turns from flashing
GREEN to solid GREEN.
• Bluetooth Pairing: Toggle the Wireless Mode Switch to
Button. Then, locate the Bluetooth icon on your PC taskbar, and click 'Add a device' to
select MSI FORCE PRO WIRELESS from the list of devices until the Status LED turns from
flashing BLUE to solid BLUE.
• If Pairing Fails: The Status LED flashes RED 3 times. Re-pair the controller using one of the
above connectivity methods.
Connect to Xbox Console (Wired Connection Only)
Power on the controller, then connect it to the console using the USB-C cable and wait until the
Status LED turns solid WHITE.
Connect to Headset
Connect a 3.5mm wired headset and unmute the microphone (muted by default) by pressing
the Mute Button.
The orange cycling effect will then appear on both thumbsticks.
Lighting Control
• Adjust Lighting Mode: Press the Lighting Switch once.
13� Lighting Switch
14� Pairing Button
15� USB-C Port
16� 3-level Trigger Locks
17� Customizable Rear Buttons
(M1/M2/M3/M4)
18� Mute Button
19� Wireless Mode Switch
20� 3.5mm Headset Jack
21� 3m USB-C to A Cable
22� Wireless USB Dongle
, and press and hold the Pairing
4
. Next, plug the
