Ermenrich LV50/LV60 PRO Laser Level
EN
Please carefully read the safety instructions and the user manual before using this product. Keep away from children.
Use the device only as specified in the user manual.
Charging the device
Connect the UBS Type-C cable to the device and DC adapter (not included) via a USB plug and connect it to the AC power supply.
Attention! The device operates from the AC power supply, as the voltage of the computer's USB port is insufficient for the proper
operation of the device.
Using
Slide the (3) switch to the unlocked position. Press (7) and hold it for 3 seconds to turn the device on or off. Press (7) to change
the brightness level.
!
WARNING: When moving the laser level or storing it, keep the switch (3) locked.
Laser beams control buttons
On the laser level
Blue button
Green button
Yellow button
Auto-leveling mode
Unlock the device. All of the laser beams will light up. The power indicator light (11) is green. If the power indication is red and
laser beams flash frequently, place the device on a flatter surface. All three laser beams can be controlled by the (4)/(8)/(9)
buttons. Lock the device and turn it off.
Locked mode
Lock the device. Press (7) and hold it for 3 seconds. All of the laser beams will be flashing. The power indicator light (11) is red. In
the locked mode, the device can be angled as needed. In this way, it is possible to project inclined lines and the autocalibration
will be switched off.
Brightness adjustment
When the device is in self-leveling or locked mode, press (7). There are four brightness levels. Press (12) on the remote control to
change the brightness level to save energy.
Pulse mode
Unlock the device. Press (7) and hold it for 3 seconds to enter pulse mode. The power indicator light (11) will be flashing.
Note! Brightness adjustment is not possible in pulse mode.
Specifications
Laser color
Laser wavelength
Working distance
Laser class
Expanded angle
Brightness levels and working time
Compensation range
Level accuracy
Tripod adapter
On the remote control
V1
H
V2
Laser level
Controls the vertical laser beam at the front of the device
Controls the horizontal laser beam
Controls the vertical laser beam on the side of the device
green
505–550nm
30m
class II
3D, 12 lines, 360° horizontal, 360° vertical
4 levels of brightness:
1 = 6h
2 = 9h
3 = 15h
4 = 30h
4°±1°
±1.5mm/5m
1/4"
5
