UK/US
USING STAR Modem™
STAR Modem™ is
433 MHz (European models) / 910 MHz (USA models) RF communication between
any serial device (Host) and Datalogic RF devices or base stations, such as:
Gryphon™ M Readers
-
Dragon™ M Laser Scanners
-
STAR Modem™ Radio Modems
-
Formula Basic Line RF Terminals (F734-E/RF, F725-E/RF, F660-E/RF)*
-
STARGATE™ Base Stations
-
* not compatible with STAR Modem™ USA models.
STAR Modem™ can be used in two different modes: Stand Alone mode and
STAR-System™ mode.
In Stand Alone mode, STAR Modem™ can be setup in uni-directional
communication to either receive (Server) data via radio from Datalogic RF devices, or
transmit (Client) data via radio to Datalogic RF devices. When working as Server,
currently supported devices are RF hand-held readers, another STAR Modem™ or
RF terminals loading STAR&Play™ software. All the multistandard interface
selections are valid (RS232, Wedge, Pen Emulation).
When working as Client, currently supported devices are another STAR Modem™
or a Datalogic OM-cradle. The only valid interface selection in RS232.
In Stand Alone mode, the system implements a different RF Narrow Band radio
protocol than STAR-System™.
In STAR-System™ mode, STAR Modem™ uniquely provides a wireless
bi-directional communication
STAR Modem™ is connected to the Host only through the RS232 interface.
For more details about
STAR Modem™ Reference Manual provided on the installation CD-ROM.
2
a radio modem developed
between the
the modem configuration options refer to the
STAR Modem™
to provide
Host and the RF
wireless
devices.
