UK/US

RS232 INTERFACE CONNECTION

Connect the modem cable directly to the PC COM Port.

PEN EMULATION INTERFACE CONNECTION

Before proceeding with this connection, configure STAR Modem™
software parameters through the RS232 interface and then set the
hardware jumper position (see "STAR Modem™ Configuration").
CAUTION
For Pen Emulation interface connection, it is necessary to use the adapter as shown
in the following figure:
4
Datalogic Standard Pen Emulation Cable
90ACC1859
STAR Modem™ Adapter
STAR Modem™
